Features
Front Panel
1. Power Button: Press this button to turn the unit on or off. Make sure the AC In is properly connected to a power
outlet. Do not turn the unit off during media playback—doing so could damage your media.
2. Aux In: Connect an optional device to this input using a 1/8” (3.5mm) TRS cable. See Operation > Playing Audio
from an External Device for more information.
3. USB Port: Connect a mass-storage-class USB device to this port.
4. CD Slot: Insert a CD into this slot. See Operation > Playing Audio CDs for more information.
5. CD/USB/Aux Button: Press this to enter Media Selection screen. See Operation > Selecting Media Playback Mode
for more information.
6. Repeat Button: In CD or USB Mode, press this button to switch between Repeat Playback modes: Repeat One
,
Repeat All
, Repeat FLD (folder), and Repeat Off. See Operation > Playing Audio CDs for more information.
Power-On Play Button: Press and hold this button to turn Power-On Play on or off. See Operation > Additional
Functions > Power-On Play for more information.
7. Random Button: In CD or USB Mode, press this button to cycle through Random Play Mode
, Single Play Mode S,
and Normal Play Mode.
8. Text Button: In CD or USB Mode, press this button to switch the display between the file name and other text
information.
Lock Button : Press and hold this button to turn Panel Lock on and off. See Operation > Additional Functions >
Panel Lock for more information.
9. Time Button: In CD or USB Mode, press this button to switch the Time Mode in the display. See Operation > Playing
Audio CDs for more information.
10. Eject Button: Press this to eject the CD in the CD slot. To force-eject a CD, power off the unit, then press and hold the
eject button while powering the unit back on. To exit force-eject mode, turn the unit off.
11. Display: This screen indicates the unit’s current operation. See Display for more information.
12. Remote Sensor: Point the remote control at this sensor when operating it. See Remote Control > Operating Range
for more information.
Note: If the remote sensor is exposed to direct sunlight, strong artificial light (like from an interverter-type fluorescent
lamp), or infrared light, the unit or remote control may not function properly.
13. Search Buttons: In CD or USB Mode, press and hold one of these buttons to rewind/fast-forward. The track will
rewind/fast-forward at 5 times the normal playback speed.
14. Stop Button: Press this button to stop playback. To view current firmware version, hold the stop button while
powering on the unit.
15. Play/Pause Button: Press this button to start, resume, or pause playback.
16. Number Buttons (0–9): In CD Mode, Press one of these buttons to directly select a track to play. If the track number is
two digits, press the buttons in succession (e.g., 1 then 2 for Track 12). See Operation > Playing Audio CDs for more
information.
17. Jog Dial: Turn this dial to browse the options shown in the display. Press this dial to confirm a selection. In CD and
USB mode this is used to browse and select tracks.
1
2
356 8
10
11
16
12
13 14 15
17
4
7
9
