12 ENGLISH
Battery pocket
A pocket is provided for storing the battery holder (with battery)
insidethejacket.Connectthepowercabletothebatteryholder,
and then put it into the pocket and fasten the snap buttons.
►Fig.22
Mesh pocket
For DFJ210 / DFJ211 / DFJ310 / DFJ311 / DFJ410 /
DFJ411 only
Meshpocketsareprovidedonthebackofthejacketfor
storing ice packs.
►Fig.23: 1. Mesh pocket
Connecting USB devices
CAUTION: Connect only devices that are
compatible with the USB power supply port. Not
doing so may cause a malfunction of the battery
holder.
NOTICE: Before connecting a USB device to
the battery holder (with the battery), always back
up the data on the USB device. Not doing so may
cause a loss of your data.
The battery holder (with the battery) can work as an
external power supply for USB devices.
Open the cover and connect a USB cable (not included)
to the power supply port of the battery holder. Then con-
nect the other end of the cable to the device and turn on
the switch next to the USB port.
The battery holder (with the battery) supplies DC5V, 2.1A.
►Fig.24: 1. Cover 2. Switch
(For DFJ210 / DFJ211 / DFJ310 / DFJ311 / DFJ410 /
DFJ411 only)
TheUSBcablecanbeplacedinsidethejacketforconve-
nience using the hole in the pocket and the cable holder.
►Fig.25: 1. USB cable
NOTE: The battery holder may not supply power to
some USB devices.
NOTE: When not using or after charging, remove the
USB cable and close the cover.
NOTE: Battery power is consumed while the switch is
turned on. Always turn off the switch when not in use.
MAINTENANCE
CAUTION: Always be sure that the jacket is
switched off and the battery cartridge is removed
before attempting to perform inspections or
maintenance.
CAUTION: If the jacket does not switch on
or any fault is found with a fully charged battery
cartridge, clean the terminals of the battery holder
and the battery cartridge. If the jacket still does
not work properly, stop using the jacket and con-
tact our authorized service center.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
Cleaning the fan unit
•
Use clean cloth to remove dirt, dust, oil, grease etc.
• Donotdisassemblethefanunitwhencleaning.
Cleaning the jacket
For all models
• Detachthefanunit(s)andbatteryholderfromthe
jacketbeforewashing.
• Followtheinstructionsonthetag.
• Cottonproductsmayshrinkwhenwashed.
• Donotwashthejacketwithotherclothes.Doing
so may cause color fading or color transfer.
• Usealaundrynetwhenusingawashingmachine.
• Donotusethefabricsoftener.
• Useonlyneutraldetergent.
• Afterwashing,takeoutthejacketfromwashing
mashine at once.
• Besuretoclosethezipfastenerbeforewashing.
For DFJ214 only
• Theperformanceoflightreectorpartsmaybe
weakened by washing.
• Machinewashingentlecycle(Thenumberof
times for washing is up to 5 times.)
• Thenumberoftimesforwashingisnottheonly
thefactortodecidethelifetimeofthejacket.
• Thelifeofthejacketchangesbyhowtouse,how
to care and store state.
• Ifthelightreectorpartsorclotheshavebeen
deteriorated,replacetoanewjacket.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual. The use of any other
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Batteryholder
• Filterset
• Makitagenuinebatteryandcharger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
differ from country to country.
