14 ENGLISH
5. Release your nger from the switch trigger. Then
lift the contact element up from the material.
To drive the next fastener, repeat the steps 3 to 5 in the
same sequence.
Contact actuation
Country specic
In this mode, you can choose either continuous or
single driving by following any sequences of the trigger
operation.
A workpiece contact and a trigger can be activated
in any sequences to actuate the tool. Release and
re-activate the workpiece contact to continuously drive
fasteners.
For a single driving
1. Press and hold the main power button to turn on
the tool.
2. Press and shortly hold the actuation mode switch
button to select the contact actuation mode.
The contact actuation mode lamp lights up.
► Fig.22: 1. Actuation mode switch button 2. Contact
actuation mode lamp
3. Place the contact element at on the material.
4. Pull the switch trigger fully to drive a fastener.
5. Release your nger from the switch trigger. Then
lift the contact element up from the material.
To drive the next fastener, repeat the steps 3 to 5 in the
same sequence.
For a continuous driving
1. Press and hold the main power button to turn on
the tool.
2. Press and shortly hold the actuation mode switch
button to select the contact actuation mode.
The contact actuation mode lamp lights up.
3. Pull the switch trigger.
► Fig.23: 1. Switch trigger
4. Place the contact element at on the material to
drive a fastener.
5. Move the tool to the next areas with the switch
trigger pulled, and place the contact element at on the
material to drive following fasteners.
► Fig.24: 1. Switch trigger 2. Contact element
Anti dry re mechanism
When the remaining fasteners in the magazine
decrease to 6 - 9 pieces for model DBN601 / 6 - 9
pieces for model DBN610, the switch can no longer be
actuated and the tool stops ring. Insert a new strip of
fasteners in the magazine before restarting operation.
Removing jammed fasteners
WARNING: Always make sure that the bat-
tery cartridge and fasteners are removed before
removing jammed fasteners.
WARNING: Do not push on the fastener driver
forcibly. Do not strike the fastener driver and fas-
teners with any hand tools to clear jams. Mind that
the tool is charged with compressed air and the pres-
sure is maintained inside. Failure to follow the safety
precautions in the manual can result in serious injury.
WARNING: Never point the tool at yourself or
other persons nearby when clearing jams. Failure
to do so may cause a risk of injury by misring since
the tool is charged with compressed air in a factory
sealed chamber.
CAUTION: Do not remove the jammed fasten-
ers with bare hands. The fastener may jump out of
the magazine and cause an injury.
CAUTION: To address frequent jamming or
hard-to-clear jamming situations, consult your
local Makita Service Center.
CAUTION: Be sure to lock the latch after
removing jammed fasteners.
When a fastener jamming occurs, look over closely
the fastener feeding and driving unit. Jams tend to be
caused by fasteners wedged between the fastener
driver and the under driver guide.
To clear a jam, release the latch and open the driver
guide, then remove the jammed fasteners.
► Fig.25: 1. Latch 2. Under driver guide 3. Driver
guide
To lock the latch after clearing a jam, return the contact
element to its original position and close the driver
guide, then lock the latch.
► Fig.26: 1. Contact element 2. Driver guide
MAINTENANCE
WARNING: Do not disassemble this tool. This
tool is sealed with compressed air and disassembly
may result in serious injury.
CAUTION: Always be sure that the tool is
switched o and the battery cartridge is removed
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
