11 ENGLISH
passofthe2to3mmrstcutandthenmakeanother
pass of usual cut.
First, push in the stopper toward the circular saw blade
for obtaining 2 to 3 mm depth of cut.
Then pull the button back for performing free depth of
cut.
Make sure that the stopper is released and the red mark
can be seen for groove cutting operation.
Connecting a vacuum cleaner
For groove cutting operation, connect a Makita vacuum
cleaner to your tool.
Connect a hose of the vacuum cleaner to the dust port.
►Fig.21: 1. Vacuum cleaner 2. Dust port
OPERATION
CAUTION: Always use a front grip and rear
handleandrmlyholdthetoolbybothfrontgripand
rear handle during operations.
Guide rail
Optional accessory
Always use the guide rail for groove cutting operation.
Place the tool on the rear end of the guide rail.
Turntwoadjustingscrewsonthetoolbasesothatthe
tool slides smoothly without a clatter.
►Fig.22: 1.Adjustingscrews
Groove cutting
CAUTION: Be sure to move the tool forward
in a straight line gently. Forcing or twisting the tool
may result in overheating the motor and dangerous
kickback,possiblycausingsevereinjury.
CAUTION: Never approach any part of your
body under the tool base when section cutting,
especially at starting. Doing so may cause serious
personalinjuries.Thebladeisexposedunderthetool
base.
CAUTION: Use eye protection to avoid injury.
CAUTION: For groove cutting operation,
always connect the tool to a vacuum cleaner.
CAUTION: Hold the tool rmly. The tool is
provided with both a front grip and rear handle.
Use both to best grasp the tool. If both hands are
holding saw, they cannot be cut by the blade.
►Fig.23
1. Adjustthedepthofcut.
2. Set the tool on the guide rail.
3. Align the guide rail along the cutting line with using
the guide plate. Make sure that the blade does not
make any contact with workpiece.
4. Pushinthelock-obuttonandturnthetoolon,
and wait until the blade attains full speed.
5. Press down the tool slowly to the preset depth of
cut, and simply move the tool forward over the work-
piecesurface,keepingitatandadvancingsmoothly
until the cutting is completed.
6. When cutting is complete, release switch, wait for
blade to stop and then withdraw tool.
To get clean cuts, keep your cutting line straight and
your speed of advance uniform. If the cut fails to prop-
erly follow your intended cut line, do not attempt to
turn or force the tool back to the cut line. Doing so
may bind the blade and lead to dangerous kickback and
possibleseriousinjury.
Plunge cutting (Cutting-out)
WARNING: To avoid a kickback, be sure to
observe the following instructions.
1. Place the tool on the guide rail with the rear edge
oftoolbaseagainstaxedstoporequivalentwhichis
clamped on the guide rail.
►Fig.24: 1. Fixed stop
2. Holdthetoolrmlywithonehandonthefrontgrip
andtheotheronthetoolhandle.Pushinthelock-o
button, and turn the tool on, then wait until the blade
attains full speed.
3. Press down the saw head slowly to the preset
depth of cut, and move the tool forward to the desired
plunge position.
NOTE: The triangular mark on the blade case shows
the approximate center of the blade.
►Fig.25: 1. Triangular mark
MAINTENANCE
CAUTION: Always be sure that the tool is
switched o and unplugged before attempting to
perform inspection or maintenance.
CAUTION: Clean out the guard to ensure
there is no accumulated sawdust and chips
which may impede the operation of the guarding
system. A dirty guarding system may limit the proper
operation which could result in serious personal
injury.Themosteectivewaytoaccomplishthis
cleaning is with compressed air. If the dust is being
blown out of the guard, be sure the proper eye
and breathing protection is used.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Replacing carbon brushes
►Fig.26: 1. Limit mark
Check the carbon brushes regularly.
Replace them when they wear down to the limit mark.
Keep the carbon brushes clean and free to slip in the
holders. Both carbon brushes should be replaced at the
same time. Use only identical carbon brushes.
1. Use a screwdriver to remove the brush holder
