6
CAUTION:
• When cutting a small portion of the workpiece, you may
have difficulty completing the end of the cut. In that
case, try to cut it again, pulling the workpiece back
slightly.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and the
battery cartridge is removed before attempting to
perform inspection or maintenance.
The tool and its air vents have to be kept clean. Regularly
clean the tool's air vents or whenever the vents start to
become obstructed.
Replacing carbon brushes (Fig. 10)
Remove and check the carbon brushes regularly. Replace
when they wear down to the limit mark. Keep the carbon
brushes clean and free to slip in the holders. Both carbon
brushes should be replaced at the same time. Use only
identical carbon brushes.
Insert the top end of slotted bit screwdriver into the notch
in the tool and remove the holder cap cover by lifting it up.
(Fig. 11)
Use a screwdriver to remove the brush holder caps. Take
out the worn carbon brushes, insert the new ones and
secure the brush holder caps. (Fig. 12)
Reinstall the holder cap cover on the tool.
Replacing blades
The service life of the blades varies in terms of the
workpiece to be cut. The following reference tables
indicate the approximate service life of the blades.
When the blades become dull, ask Makita Authorized
Service Centers to replace the blades.
To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be
performed by Makita Authorized Service Centers, always
using Makita replacement parts.
ACCESSORIES
CAUTION:
• These accessories or attachments are recommended
for use with your Makita tool specified in this manual.
The use of any other accessories or attachments might
present a risk of injury to persons. Only use accessory
or attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Thickness gauge
• Center blade
• Side blade R
• Side blade L
•Hex wrench
• Various type of Makita genuine batteries and chargers
For Model BJS160
For European countries only
Noise
ENG104-1
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
): 74 dB (A)
Uncertainty (K): 3 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection.
Vibration
ENG218-2
The vibration total value (tri-axial vector sum) determined
according to EN60745
Work mode: cutting sheet metal
Vibration emission (a
h
): 12.0 m/s
2
Uncertainty (K): 1.5 m/s
2
For Model BJS161
For European countries only
Noise
ENG104-1
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
): 71 dB (A)
Uncertainty (K): 3 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection.
Vibration
ENG218-2
The vibration total value (tri-axial vector sum) determined
according to EN60745
Work mode: cutting sheet metal
Vibration emission (a
h
): 13.0 m/s
2
Uncertainty (K): 1.5 m/s
2
EC Declaration of Conformity ENH101-12
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):
Designation of Machine: Cordless Metal Shear
Model No./ Type: BJS160, BJS161
are of series production and
Conforms to the following European Directives:
98/37/EC until 28th December 2009 and then with
2006/42/EC from 29th December 2009
And are manufactured in accordance with the following
standards or standardised documents:
EN60745
The technical documentation is kept by our authorised
representative in Europe who is:
Makita International Europe Ltd,
Michigan, Drive, Tongwell,
Milton Keynes, MK15 8JD, England
30th January 2009
Tomoyasu Kato
Director
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi, JAPAN
Material
Cutting thickness
(mm)
Life of blades
(m)
Mild steel plate
(SPCC)
1.6 200
Stainless steel
plate
(SUS304)
1.2 150
Aluminum plate
(A-5052)
2.5 400
