Canadian
English rating
Canadian
French rating
Description
All
Locked All Ratings
E
Exempt Program
C
– For All Children
C8+
– For All Children 8 and Older
G
General Audience
–
8ans+
Unsuitable for Ages under 8
PG
– Parental Guidance Suggested
–
13ans+
Unsuitable for Ages under 13
14+
– Unsuitable for Ages under 14
–
16ans+
Unsuitable for Ages under 16
18+ 18ans+
Adult Audience Only
O
Note(s)
●
The V-Chip can Block Non Rated Programs as per “CEA-608-E
sec. L.3”. If the Option to Block NR, None or E Programs are
used in US movie ratings lock, US TV ratings lock, Canadian
English rating or Canadian French rating accordingly “unusual
results may occur and the Unit may not Receive Emergency
Bulletins or other Types of Programming”: / Emergency Bulletins
(Such as EAS messages, Weather Warnings and Others) / Locally
originated Programming / News / Political / Public Service
Announcements / Religious / Sports / Weather.
Setting your Location to Home
You can set the Location of your TV to Home or Retail.
Choosing Home gives you full flexibility to change predefined
settings for Picture and Sound.
1
Press MENU and use H I to select Features, then press
OK.
- -
Home
Software upgrade
E-sticker
Location
fun-Link (HDMI CEC)
Child lock
PC settings
Caption settings
USB
Language
Features
Setup
Sound
2
Use H I to Select Location, then press OK.
3
Use H I to Select Home, then press OK.
O
Note(s)
●
You must set Home in the Menu. Otherwise, personalized
Picture and Sound Settings will Not Be Memorized after the Unit
goes into Standby Mode.
Viewing Photos and Videos on a USB
Memory Stick
Your TV is fitted with a USB connection that enables you to view
Photos or Videos (Motion JPEG files) stored on a USB Memory
Stick.
1
Press MENU and use
H
I
to select USB, then press OK.
●
The Highlighted Text will move to Start now, then press OK again.
2
Use
H
I
to Select the Picture or Video, then press OK.
●
These Recorded Files must meet Specifications shown below:
(JPEG)
Upper limit 4000 x 4000 pixels
Video
(Motion
JPEG)
Size 320 x 240 (QVGA)
Frame rate 30fps
Audio type LPCM
Sampling frequency
(32 kHz, 44.1 kHz or 48 kHz)
Quantization bit rate (16 bit)
O
Note(s)
●
We cannot be held responsible if your USB Memory Stick is Not
Supported, nor will we accept any liability for damage or loss of stored
data.
●
The USB Memory Stick is Not Supplied with this TV.
●
A File Name exceeding 128 characters or contains a Dot character is
Not Supported on this TV.
●
Progressive JPEG files are Not Supported.
●
Only a Motion JPEG file with an “.avi” extension is supported. An
extension “.mov” is Not Supported.
●
During Motion JPEG Playback, “Pause”, “Forward” and “Reverse” Do
Not Work on this Unit.
5 Install Channels
Autoprogram
Be sure the RF cable is correctly connected to this Unit and
you are registered with your Cable TV provider when you
Install Cable channels.
1
Press MENU and use H I to select Setup, then press
OK.
2
Use H I to Select Autoprogram, then press OK.
●
If you run Autoprogram when you have Locked Channels, a
Message appears asking to enter your PIN. Enter your PIN in
order to Complete the Installation. You need to set the
Channel Lock again after the Installation.
3
Use H I to Select an appropriate Option, then press
OK.
–
When Antenna is selected, the TV Detects Any Off-the-Air
Antenna Signals. It searches for ATSC (Digital) and NTSC
(Analog) Channels available in your Area.
–
When Cable is selected, the TV Detects Signals supplied by
Cable. It searches for ATSC (Digital), NTSC (Analog) and
Cable Channels available in your Area.
Cable
Antenna
Back
ANTENNA IN
Or
Cable
Antenna
Select your signal source.
Language
Features
USB
Setup
Sound
####
than 20 minutes to complete.
Auto programming may take more
Auto program will rescan all channels.
●
When the Scanning and Memorizing of Available Channels is
Completed, the Lowest Memorized Channel will be
Displayed.
4
Follow the On-screen Instructions to Complete the
Installation.
10
