Timing Parameters

Item Description

Adjust Timing

When the signal is being captured, the device will automatically recommend one or more timings as shown in the Preferred timings list. The first one in the list will be shown

above the timing adjustment section by default. If none of the recommended timing matches, users can drag the slider bars below to manually adjust. This method is not

recommended if adjusting by adding a GTF/CVT resolution is possible.

When the following data are modified, the corresponding data in the Info and Input tab would change synchronously.

Custom Timings

Custom GTF/CVT

Resolutions

If adjustments made in the Timing Adjustment tab cannot achieve satisfactory results, users can manually add the resolution that meets GTF or CVT standards.

H active: the number of Horizontal timing active pixels■

H total: the total number of Horizontal timing pixels■

H offset: Horizontal offset■

V active: the number of Vertical timing active pixels■

V offset: Vertical offset■

Clamp position■

Aspect Ratio: If Video > INPUT > Aspect ratio is ticked, it would keep the customize data. Otherwise, it would change as it is set here.■

Customize timing: Click Save as custom timing to save the correct timing setting in the Custom Timings list. When the same video signal is connected again, the card will

automatically show the video according to the previously saved setting.

■

Reset timing: Click Reset timing to set the custom timing as the current timing. If no custom timing is available, the first one in the recommended list will be set as the current

timing.

■

Shows the custom timing list. When the same video signal is connected again, the card will automatically show the video according to the previously saved setting.■

Delete: If the users want to delete the past setting(s), they can choose the setting in Custom timings and click Delete.■

Add: If the recommended timings don’t match the input and the input signal is in the standard GTF or CVT format, users can click Add... to input the resolution.

USB Capture Utility V3 automatically generates new timing based on added resolution, which is simpler, faster, and more recommended than dragging a slider.

■

Modify: Choose a resolution in the list and click the Modify... button.■

Delete: Choose a resolution in the list and click the Delete button.■
