Adjust timing

When the signal is being captured, the device will automatically recommend one or more timings as shown in the Preferred timings list. The first one in the list will be

shown above the timing adjustment section by default. If none of the recommended timing matches, you can drag the slider bars below to manually adjust.

Item Name Item Description

H active Active horizontal picture width.

H total Total horizontal pixels captured.

H offset

Set the value to move the image horizontally.

Note: The dimensions have the following relation: H total >= H active + H offset, for example, H active = 1920, H total = 2200, as a result,

H offset <= 280.

V active Active vertical picture width.

V offset

Set the value to move the image vertically.

Note: The dimensions have the following relation: V total >= V active + V offset, for example, V active =1080, V total=1125, as a result V

offset <= 45.

Clamp position Used to adjust the sampling point of A/D conversion to remove interference, usually do not need to be modified.

Aspect ratio Set the aspect ratio of input video.

To add a new custom timing:

To reset timing:

Click Save as custom timing to save the correct timing setting in the Custom Timings tab. When the same video signal is connected again, the card will

automatically show the video according to the previously saved profile.

■

Click Reset timing to set the custom timing as the current timing. If no custom timing is available, the first one in the recommended list will be set as the current

timing.

■
