Timing-H sync

width

Shows width of the horizontal sync pulse.

Timing-H back

porch

Shows pixel width between the end of the

horizontal sync pulse and the start of the next

active horizontal picture line.

Timing-V total

Shows total vertical pixels (i.e. Picture lines)

captured.

Timing-V active Shows active vertical picture height.

Timing-V front

porch

Shows number of lines between the last line of the

active vertical picture area and the start of the

vertical sync pulse.

Timing-V sync width Shows width of the vertical sync pulse, in lines.

Timing-V back

porch

Shows number of lines between the end of the

vertical sync pulse and the start of the next active

horizontal picture line.

Item Name Item Description

NOTE:

When the input video signal is in interlaced format, the table will include

information for each field separately (Field-0 and Field-1) in the vertical

direction.

■

When DVI signal is connected, the parameters in the Input specific status

tab is the same as those of HDMI.

■
