6
Before connections
Before connecting other devices, connect of the accessory
power cable to the AC inlet of this unit.
When connection is performed, turn off the operation switch-
es of this unit and all other connected devices to prevent an
accident caused by unexpected noise.
How to connect power supply
Use the accessory power cable and insert the AC plug in an
outlet on the wall in the room where the unit will be installed.
How to connect CD player, DVD player,
tuner, or other devices
Connect the output terminal of a reproducing device such as
a CD player and the line input terminal (CD, LINE-1, LINE-2,
or LINE-3) of this unit with 2 (R and L) pin-plug cables.
Use caution not to conduct wrong connection between right
and left.
How to connect analog record player
Connect between the output terminal of the analog record
player and the PHONO terminal of this unit with 2 (R and L)
pin-plug cables.
For some types of players, the ground wire from the phono
motor or tone arm should be connected to the signal ground
terminal of this unit.
The output from an analog record player equipped with a
phono equalizer or from an independent phono equalizer shall
be connected to the line input terminal (CD, LINE-1, LINE-2,
or LINE-3) of this unit.
How to connect speakers
Connect the left-channel speaker to the left speaker terminal
of this unit and the right-channel speaker to the right speaker
terminal.
Securely connect the (+) terminal of the speaker system to the
speaker terminal (+) (red) of this unit, and the (-) terminal of the
speaker system to the speaker terminal (-) (black) of this unit.
If the (+) and (-) terminals are reversely connected to either of
the right and left speaker systems, the acoustic phases of the
sound reproduced from the right and left speaker systems
are also reversed. In such a case, be aware that the sound
level in the low range will be reduced and the acoustic stability
will worsen, thus failing in normal stereo playback.
Connections and Connection Diagram
