20
Specifications
Phono motor section
Drive system Belt drive system
Motor Reaction and AC synchronous motor
Platter 30 cm machined alminum plate (weight 5.0 kg)
Revolution 33 1/3 rpm, 45 rpm (2 speeds selectable)
Revolution adjustment range ±5% (each rotation speed adjustable independently)
Wow and flutter 0.04% or less (W.R.M.S)
Tone arm section
Format Static balance, S-type
Length overall 229mm
Tracking error angle +1.9° to –1.1°
Overhang 15mm
Applicable cartridge weight 4 g - 12 g * 22 g - 32 g when a heavy counterweight (option) is used
Adjustable height range 38 to 60mm
Anti-skating 0 to 3g
Attached equipment and others
Attached equipment
[Top panel section]
• Power switch • Start/stop switch
• Rotation speed selection switch • Stroboscope
• Rotation speed fine tuning volume (speed control) (33 1/3 rpm, 45 rpm)
• Stylus light connector • Arm (arm base mounted)
[Rear panel section]
• AC inlet
[Bottom section]
• Insulator • Tone arm connector (DIN5P type)
Accessories
• Platter • Power cable
• Dust cover • Stylus light • Headshell
• Pulley cover • Rubber belt • EP adaptor
• Rubber mat • Phono cable (connected to main unit)
• Counterweight • Platter mount handle (2 pieces)
• Tone arm adjustment wrench (2.5 mm)
• Arm lifter adjustment wrench (1.5 mm)
• Arm base cover removal wrench (3.0 mm)
• Phono cable securing cushions (3 types)
• Dustproof cap for stylus light connector (connected to main unit)
Power source 230 V ~ (50 Hz)
Power consumption 38 W
Weight 25.4 kg
Dimensions
492 (W) × 140 (up to top face of platter), 195 (with dust cover mounted) (H)
× 407 (10 mm of fittings on rear face included) (D) mm
Ambient operating temperature /
Ambient operating humidity
–5 °C to +35 °C / 5% to 85% (non condensing)
* Design and specifications are subject to change without notice.
