BELT DRIVE ANALOG PLAYER PD-171A
13
10. How to mount pulley cover
Insert four corners slowly and evenly as shown below.
11. How to mount rubber mat
The face with a hollow in the center is the upper side.
Put the rubber mat on the platter by aligning it with the cen-
ter spindle.
12. How to mount dust cover
The dust cover has a plug-in type hinge.
Insert the hinge attached to the dust cover into the hinge
receiver attached to the rear side of the main unit all the way
in a straight manner.
If the acrylic portion of the dust cover is pushed firmly, it may
be cracked. Therefore, insert rather than push the hinge por-
tions at the right and left sides at the same time.
