73

Manufacturer Commands

0: Off 1: On

0: 30 sec 1: 1 min 2: always on

0: black out 1: last settings on 2: last settings 1 min

0: 8 bit 1: 16 bit

0: 2800-10000 1: 3200-5600

FAN MODE

DISPLAY TIMEOUT

DMX SIGNAL LOST MODE

DMX BITS

CCT LIMIT

0x8001

0x8002

0x8003

0x8004

0x8005

0: linear 1: exponential 2: logarithmic

0: full speed 1: normal speed 2: high speed 3: low speed

LINEARIZATION

FILTER

0x8006

0x8007

0: 18 KHz 1: 25 KHz

0: not inverted 1: inverted

FREQUENCY

INV - CCT

0x8008

0x8009

Display: 30sec / 1min / ALWAYS ON. Time during which the display backlight stays on.

Menù View: Type the main MENU, sub-menus and functions to show. ONLY MANUAL / ONLY DMX / MANUAL/DMX.

Frequency: Dimmer frequency 18 KHz - 25 KHz

Filter: FULL SPEED / NORMAL SPEED / HIGH SPEED / LOW SPEED. It is the speed response of the system (smooth

factor).

Linearization: LINEAR / EXPONENTIAL / LOGARITHMIC. Linearization is the compensation curve for the human eye's

perception of the luminous intensity emitted as a function of the required power (required power = dimmer value on

the display).

- Linear: No compensation, the intensity of the light is directly proportional to requested power

- Exponential: The light intensity increases from 0 to 100 exponentially.

- Logarithmic: The light intensity increases from 0 to 100 logarithmically.

CCT Limit: CCT range 2800 - 6500 or 3200 - 5600

DEVICE SETTINGS

1. To set the factory settings, select YES by pressign the

2

button.

2. Press « OK »

3

to conrm the selection.

3. The device will ask for further conrmation, select YES by pressing the

2

button.

4. Press « OK »

3

to conrm the selection.

FACTORY SETTINGS: Mode: CCT or MONOCOLOR - DMX: Off - Bit: 8bit - DMX signal loss: Settings 1 Min -

Display: 1 Min - Filter: Normal Speed - Linearization: Linear

RESET DEVICE

BLUETOOTH

DEVICE SETTINGS

DISPLAY: 1 min

MENU VIEW: Manual/DMX

FILTER : Normal speed

LINEARIZATION: Linear

CCT LIMIT: 2800K - 10000K

FREQUENCY: 18 KHz

BLUETOOTH

Bluetooth Active: OFF

MANUAL OPERATION

MODE: CCT

DMX OPERATION

MODE: CCT

BIT: 8 BIT

DMX SIGNAL LOSS: Settings 1 MIN

RDM ENABLE: OFF

INV - CCT: OFF

FACTORY DEFAULT SETTING

1. Press the

3

button four times to enter the main MENU, then press the « »

1

or « »

2

buttons to enter in the

conguration menu.

2. Navigate through the main MENU with the « »

1

or « »

2

buttons and press the

3

OK button to conrm the

MANUAL option.
