DMX OPTIONS2

1. Use the « »

or « »

buttons to select between the MONOCOLOR / CCT MODE* / ADVANCED MODE.

2. Press the « OK »

button to conrm the selection.

*The mode name changes according to the Dayled model (monocolor or dual color).

Press the « OK »

buttons to select the EFFECT.

1. Use the« »

or « »

buttons to select between DMX OPERATION / DMX BIT / DMX SIGNAL LOSS.

2. Press the « OK »

button to conrm the selection.

DMX BIT: Resolution of the DMX control.

1. Press the « OK »

button to enter to the DMX BIT options.

2. Use the « »

or « »

buttons to select between 8bit or 16bit.

3. Press the « OK »

button to conrm the selected setting. See protocol DMX.

8bit: 1 channel per function. 16 bit: 2 channels per function.

DMX SIGNAL LOSS: This allows to choose the device’s behaviour in case of a DMX signal loss.

1. Select the DMX SIGNAL LOSS item with the

button.

2. Use the « »

or « »

buttons to select the device’s behaviour between BLACK OUT /SETTINGS LAST/

SETTINGS 1min.

3. Press the « OK »

button to conrm the setting.

Black out: The device switches off. Settings Last: The values of the last selected setting are maintained over time

until the device is switched off. Settings 1min: The values of the last selected settings will be maintained for one

minute and then the device will switch off.

1. Press the « OK »

button to enter the DEVICE SETTINGS options.

2. Use the « »

or « »

buttons to select between DISPLAY / FILTER / LINEARIZATION.

3. Press « OK »

button to conrm the selection.

4. Within each function select the option to be activated, use the « »

or « »

buttons to select one between the

options, press « OK »

button to activate it.

INV CCT: ON/FF: enable/disable reversal CCT console control

DMX Protocol

DMX Channel Protocol - 8 bit

DMX Channel Protocol - 16 bit

MODE

CHANNELS

DMX CHANNEL POSITION DMX VALUE VALUE

CCT 6

1. DIMMER - byte 1

2. DIMMER - byte 2

0 - 65535

0 ÷ 2620

2621 ÷ 65535

0 ÷ 100 %

6500 - 2700

strobe off

-1,00 ÷ +1,00

3. COLOR TEMPERATURE - byte 1 *

4. COLOR TEMPERATURE - byte 2 *

5. STROBE - byte 1

6. STROBE - byte 2

*Channel in use only the Dual Color version.

** Only available if enabled in DMX ADVANCED.

MODE CHANNELS

DMX CHANNEL POSITION DMX VALUE VALUE

CCT 2/3*

1. DIMMER 0 - 255 0 - 100 %

0 ÷ 5 Ø

2. COLOR TEMPERATURE 0 - 255 6500 - 2700

6 ÷ 255 1 ÷ 25 Hz

3. *STROBE CONTROL
