Je bekijkt pagina 6 van 83

7

CONTROL PANEL

- In current mode press the

2

push button to enter the main MENU.

- In the sub-menus press the

2

push button to conrm a selection.

- Rotate the

2

knob to navigate in the main MENU and sub-menus.

- Use the « INTENSITY »

2

knob to adjust the light intensity from 0 to 100%.

- Use the knob

1

to adjust the light mode parameters.

- Display

3

.

ATTENTION: The light intensity level is adjustable from 0 - 50% if the FAN is OFF. The value on the display ashes.

MODE

1. Press the

2

push button to enter the main MENU.

2. Select MODE by pressing the

2

push button.

3. Select the light mode among CCT with the

2

knob and press the

2

push button to conrm selection.

4. Select among CCT / PRESET / SAVE PRESET with the

5

knob and press the

5

push button to conrm selection

5. See LIGHT MODES.

LIGHT MODES

DMX OPERATIONS

BLUETOOTH

MODE

CCT

CCT/HUE

5

CT 2800 K to 10000 K - -

GN/SAT/COLOR

6

GN/SAT/COLOR

6

INTENSITY

4

Light Intensity

CCT MODE: Warm and cold white control mode. It allows you to adjust colour temperature (CCT), and light intensity.

This is the default setting.

ATTENTION: Rotating the

1

knob changes the CT value- Pressing

1

button select GN

value that can be changed by rotating the same

1

knob.

1. Press the

2

push button to enter the main MENU.

2. Select CONTROL with the

2

knob and press the

2

push button to conrm selection.

3. Select DMX with the

2

knob and press the

2

push button to conrm selection.

4. Select the DMX channel, rotating the

1

knob to change DMX ADDRESS in ascending or descending order among 1

and 512. The number shown on the display

3

is the selected channel to communicate with the control desk.

5. See DMX PROTOCOL MANUAL for DMX channel specication.

NOTE: The symbol - ! - on the display indicates that there is no DMX signal.

1. Press the

2

push button to enter the main MENU.

1. Select CONTROL with the

2

knob and press the

2

push button to conrm selection.

2. Select BLE with the

2

knob and press the

2

push button to conrm selection.

DMX OPERATIONS - Advanced Settings

1. Press the

2

push button to enter the main MENU.

2. Navigate through the main MENU with the

2

knob until DEVICE SETTINGS and press the

2

push button to conrm

selection.

3. Rotate the

2

knob to select DMX ADVANCED, press the

2

push button to conrm selection.

4. Select one of the options among the DMX BIT, DMX SIGNAL LOSS, RDM ENABLE, STROBE ENABLE and INV CCT
