• Max input current for daisy chain: 15 A

• Device for indoor use only.

• Protection standard IP20.

• Maximum ambient temperature: 45 °C.

• Make sure power supply plug is suitable to power required.

• As prescribed by international regulations, a safety cable must be used when the xture is suspended from

ceiling.

• To switch on the light push the on/off button.

• Dayled 650 and Dayled 1000 models are equipped with new generation high quality LED arrays.

• Dayled 650 PRO is equipped with 60 W single LED array.

• Dayled 1000 PRO is equipped with 110 W single LED array.

• Dayled 2000 PRO is equipped with 220 W single LED array.

Instructions

Dayled 2000 PRO

Dayled 1000 PRO

Getting Started with the Dayled PRO

Barndoors

screw lock

Tilt lock knob

Barndoors

bracket

Locking knob

Barndoors

screw lock

Tilt lock knob

Barndoors

bracket

Locking knob

Focus knob

(Flood/spot)

Battery connector

(Male 4 PIN XLR)

ON/OFF

DMX INPUT

(Male 5 PIN XLR)

DMX THROUGH

(Female 5 PIN XLR)

Focus knob

(Flood/spot)

Battery connector

(Male 4 PIN XLR)

ON/OFF

DMX INPUT

(Male 5 PIN XLR)

DMX THROUGH

(Female 5 PIN XLR)

POWERCON IN

POWERCON OUT

(Max 15 A)

POWERCON OUT

(Max 15 A)

FUSE

(15 A)

FUSE

(15 A)

1

2

3

MODE button

button

1

2

3

MODE button

button
