• Device for indoor use only.

• Maximum ambient temperature: 40 °C.

• Make sure power supply plug is suitable to power required.

• As prescribed by international regulations, a safety cable must be used when the xture is suspended from

ceiling.

• To switch on the light push the on/off button.

• Superpanel models are equipped with new generation high quality powerleds.

Instructions

Getting Started with the Actionpanel

Screw hole for V-Mount

battery bracket

Screw hole for

adapter bracket and

barndoors/diffuser

Silent FAN

ON/OFF

Intensity knob

Tilt lock knob

Display

DMX THROUGH

(Female 5 PIN XLR connector)

DMX INPUT

(Male 5 PIN XLR connector)

Stirrup

CCT knob

Power IN connector

Locking knob

Turning on the Actionpanel

Place the AC Adapter in the

mounting bracket via the 2

captive screws to the bottom

of the ACTIONPANEL xture.

1

Insert the power cord

cable into the AC adapter

and connect the xture to

the power plug.

2

Insert the DC connector

into the input jack on the

ACTIONPANEL and power on

the xture.

3

5

4

1

6

3

UP buttonDOWN button
