Product Information

Retrieves a variety of information about the device that is

normally required by a controller.

Text description of up to 32 characters for the device

model type.

DEVICE INFO

DEVICE MODEL

DESCRIPTION

0x0060

0x0080

This parameter provides an ASCII text response with the

Manufacturer name for the device. “LUPO” is the default

name.

MANUFACTURER LABEL 0x0081

Set the device to its factory defaults. Get: Check if

settings still in default state -> 1 if default

Retrieves software version string of main software

FACTORY DEFAULTS

SOFTWARE VERSION LABEL

0x0090

0x00C0

DMX mode

The identify ag (ashes the light)

Shows a description of a DMX-Mode, max 32 characters

DMX address

DMX PERSONALITY

IDENTIFY DEVICE

DMX PERSONALITY

DESCRIPTION

DMX START ADDRESS

0x00E0

0x1000

0x00E1

0x00F0

DMX512 Setup

Control

Manufacturer Commands

0: Off 1: On

0: 30 sec 1: 1 min 2: always on

0: black out 1: last settings on 2: last settings 1 min

0: 8 bit 1: 16 bit

0: 2800-10000 1: 3200-5600

FAN MODE

DISPLAY TIMEOUT

DMX SIGNAL LOST MODE

DMX BITS

CCT LIMIT

0x8001

0x8002

0x8003

0x8004

0x8005

0: linear 1: exponential 2: logarithmic

0: full speed 1: normal speed 2: high speed 3: low speed

LINEARIZATION

FILTER

0x8006

0x8007

0: 18 KHz 1: 25 KHz

0: not inverted 1: inverted

FREQUENCY

INV - CCT

0x8008

0x8009

DEVICE SETTINGS

1. Press the

push button to enter the main MENU.

2. Navigate through the MENU rotating the

button, select DEVICE SETTINGS, press the

push button to conrm

the selection.

3. Navigate through the FAN / DISPLAY / MENU VIEW / FREQUENCY / FILTER / LINEARIZATION / CCT LIMIT

functions, rotating the

button to select the desired function and press the

push button to conrm the

selection.

4. Within each function select the option to be activated and rotate the

button.

Fan: Fan operation. ON / OFF.

When the fan is OFF the light intensity is adjustable between 0 and 50%.

Display: Time during which the display backlight stays on. 30sec / 1min / ALWAYS ON.

Menu View: Type the main MENU, sub-menus and functions to show. ONLY MANUAL / ONLY DMX / MANUAL/

DMX.

Frequency: Dimmer frequency 18 KHz - 25 KHz

Filter: It is the speed response of the system (smooth factor).

FULL SPEED / NORMAL SPEED / HIGH SPEED / LOW SPEED.

Linearization: Linearization is the compensation curve for the human eye's perception of the luminous
