CONTROL PANEL

- In current mode press the

2

push button to enter the main MENU.

- In the sub-menus press the

2

push button to conrm a selection.

- Rotate the

2

knob to navigate in the main MENU and sub-menus.

- Use the « INTENSITY »

2

knob to adjust the light intensity from 0 to 100%.

- Use the knob

1

to adjust the light mode parameters.

- Display

3

.

ATTENTION: The light intensity level is adjustable from 0 - 50% if the FAN is OFF. The value on the display ashes.

MODE

1. Press the

2

push button to enter the main MENU.

2. Select MODE by pressing the

2

push button.

3. Select the light mode among CCT with the

2

knob and press the

2

push button to conrm selection.

4. Select among CCT / HSI / RGBW / PRESET / EFFECT / SAVE PRESET with the

5

knob and press the

5

push button

to conrm selection

5. See LIGHT MODES.

LIGHT MODES

DMX OPERATIONS

BLUETOOTH

MODE

CCT

RGBW

HSI

PRESET

CCT/HUE

5

CT 2800 K to 10000 K

HUE 0° to 100°

-

-

GN - 1.00 to + 1.00 -

SAT 0 to 100% -

Select function R/G/B/W/CT/GN Change values of the function

- Change Preset

GN/SAT/COLOR

6

GN/SAT/COLOR

6

INTENSITY

4

Light Intensity

from 0 to 100%

CCT MODE: Warm and cold white control mode. It allows you to adjust colour temperature (CCT), green/magenta

compensation (GN) and light intensity. This is the default setting.

1. In MODE menu select EFFECT MODE.

2. Select the EFFECT to be activated with rotate the

2

button, conrm the selection by pressing the

2

push button.

3. Use the knob

2

to change the DIMMER and the knob

1

to adjust the effect setting values.

ATTENTION: Rotating the

1

knob changes the CT value- Pressing

1

button select GN

value that can be changed by rotating the same

1

knob.

1. Press the

2

push button to enter the main MENU.

2. Select CONTROL with the

2

knob and press the

2

push button to conrm selection.

3. Select DMX with the

2

knob and press the

2

push button to conrm selection.

4. Select the DMX channel, rotating the

1

knob to change DMX ADDRESS in ascending or descending order among 1

and 512. The number shown on the display

3

is the selected channel to communicate with the control desk.

5. See DMX PROTOCOL MANUAL for DMX channel specication.

NOTE: The symbol - ! - on the display indicates that there is no DMX signal.

1. Press the

2

push button to enter the main MENU.

1. Select CONTROL with the

2

knob and press the

2

push button to conrm selection.

2. Select BLE with the

2

knob and press the

2

push button to conrm selection.
