13
ORIGINAL INSTRUCTIONS
GB
PROPERTIES OF THE TOOL
The angular grinder is an electric tool designed for grinding and cutting metals as well as mineral construction materials, such as
bricks, natural and artifi cial stone, concrete, glaze, etc. with abrasive disks and grinding wheels selected for the given material.
The tool must not be used for processing other materials than those mentioned above, e.g. for grinding and cutting wood or polish-
ing. A correct, reliable and safe functioning of the grinder depends on its proper use, so:
Before you proceed to operate the grinder, read the manual thoroughly and keep it.
Always use protective goggles!
Do not use grinding wheels whose maximum acceptable tangential velocity is lower than 80 m/s!
Do not use grinding wheels whose maximum acceptable rotational speed is lower than the rotational speed of the grinder.
The supplier will not be held responsible for any damage resulting from the safety regulations and the recommendations indicated
hereby not being observed.
EQUIPMENT
Grinders are supplied with the following elements:
- additional handle
- guard of the grinding disk
- key for fasten the grinding disk
Abrasive disks are not included.
TECHNICAL PARAMETERS
Parameter Unit of measurement Value
Catalogue number 79125
Mains voltage [V] 230-240
Mains frequency [Hz] 50
Nominal power [W] 500
Nominal rotation [min
-1
] 11500
Diameter of the grinding disk [mm] 125
Diameter of the hole of the grinding disk [mm] 22
Spindle end M14
Mass [kg] 1,4
Level of noise
- acoustic pressure L
pA
± K
pA
[dB (A)] 88,0 ± 3,0
- power L
wA
± K
wA
[dB (A)] 99,0 ± 3,0
Level of vibrations
ah,AG
± K [m/s
2
] 6,92 ± 1,5
Insulation class II
Protection grade IP20
GENERAL SAFETY CONDITIONS
NOTE! Get acquainted with all the instructions below. Failure to observe them may lead to an electric shock, fi re or injuries. The
notion of electric tool used in the instructions applies to all the tools which are powered with electric current, both wire tools and
wireless ones.
OBSERVE THE FOLLOWING INSTRUCTIONS
Place of work
The place of work must be properly illuminated and clean. Disorder and poor illumination may be a cause of accidents.
Do not work with electric tools in explosive environments, or those which contain infl ammable liquids, gases or vapours.
Electric tools generate sparks, which may cause a fi re in case of contact with infl ammable gases or vapours.
Do not allow children and outsiders to the place of work. A lack of concentration may result in a loss of control over the tool.
Electric safety
The plug of the power supply cable must fi t the mains socket. Do not modify the plug. Do not use any adapters whatso-
ever in order to adapt the plug to the socket. Unmodifi ed plug which fi ts the socket reduces the risk of an electric shock.
Avoid contact with grounded surfaces, such as pipes, heaters and refrigerators. Grounding of the body increases the risk
of an electric shock.
