13
GB
ORIGINAL INSTRUCTIONS
After fi nishing work, move the switch to the “off ” position - O, wait for the steam to stop escaping from the nozzle. Place the device
on a level, fi rm and stable surface, unplug the power cord from the socket and leave the product to cool down completely.
MAINTENANCE AND STORAGE
After use, disconnect the product from the power supply by pulling out the power cord plug and wait until the water in the tank
has cooled down completely. Then unscrew the tank cap and empty the tank completely by turning the device upside down. Then
leave the device with the tank open until the remaining water from the tank has been completely dried. After drying the tank, screw
the cap back on.
The cloth pads will be damp after use, remove them and leave to dry. Pads can be washed in mechanical washing machines at
temperatures up to 60 degrees C. Do not dry mechanically and do not iron.
Clean the housing of the unit with a slightly damp cloth, then dry or leave to dry. Never immerse the device housing in water or
other liquids. Do not use alcohol, solvents, corrosive or abrasive agents for cleaning.
Do not use sharp objects for unclog the nozzles. Clogged nozzles must be replaced with new nozzles before further use.
Store the product in dry, shaded and well ventilated places. The place of storage should protect the device from access by unau-
thorised persons, especially children. It is recommended to store the product in the packaging it was delivered in.
TECHNICAL DATA
Parameter Units Value
Cat. No. 67220
Rated voltage [V~] 220 - 240
Rated frequency [Hz] 50/60
Rated power [W] 1500
Water tank capacity [l] 0.55
Maximum steam temperature [
O
C] 110
Capacity [g/min] 10 - 26
Ingress protection rating IPX4
Protection class I
Weight [kg] 1.4
UV lamp rated voltage [VDC] 4.5
UV lamp batteries 3 x AA
