9
Chapter 4 Remote Control and Setting Menu
4.1 Remote control
No. Item Description
1.
Power
Power on / off
2.
Preset
0-9: Click to call the preset
Preset: Assign a preset number (0-9) to save the current position
Reset: Select a preset number (0-9) to clear its position
3.
Menu
Display OSD menu
4.
Pan/ Tilt/ Enter
Pan / Tilt: Move the camera head
Home / Enter: Go back to Home position / Execute
5.
Info
Status information
6.
Zoom
Fast: high speed zoom / Slow: low speed zoom
7.
Focus
Auto: Auto focus
Manual: Enable Manual Focus
Far/ Near: Adjust the focus in Manual mode
8.
Auto Tracking
On/Off: Enable/Disable Auto Tracking
Full: Frames presenter’s full body
Upper: Frames presenter’s torso
Switch: Switch target to a different presenter
9.
L/R Direction Set
L/R Direction / Normal
10.
Mirror
Rotate the image (OFF / Mirror / Flip / Rotate)
11.
Camera select
Choose Camera ID 1 - 3
12.
Back Light
Turn on/off back light compensation
13.
Pan/Tilt Reset
Clear the Pan/Tilt setting
14.
Auto Framing
(or ON/ OFF)
Enable/ Disable Auto framing
※Please refer to Note 1 for details.
15.
Voice Tracking
(or Trigger)
VC-TR61/ VC-TR61N not supported
※Please refer to Note 1 for details.
※Note 1: The labeling of buttons #14/ #15 may vary depending on the remote control version.
Please refer to the image on the left for details.
(The labeling differs, but the functions are the same.)
#14 Auto Framing = Auto Framing On/Off
#15 [Voice Tracking] or [Trigger]:
When used with a camera that supports voice tracking: on/ off the voice tracking function.
When used with a camera that does not support voice tracking:
Single-lens: Auto framing will reset to wide angle and reframe automatically.
Dual-lens: No corresponding action.
※Dual-lens cameras feature a built-in wide-angle lens for improved framing,
eliminating the need for manual calibration.
New version
Previous version
⓫
⓬
⓭
⓮
⓯
➊
➋
➌
➍
➎
➏
➐
➑
➓
➒
