English-10
4.2 Menu
Press [MENU] on the remote control to enter the setting menu; the bold underlined
values in the following table are defaults.
1st Level 2nd Level
3rd Level Function Descriptions
Exposure
Mode
Full Auto/ Shutter
Pri/ Iris Pri/ Manual/
White Board
Exposure mode setting
Spot Light On/ Off Turn on/off Spot Light
Spot Light Position X(0~6)Y(0~4) Adjustable after
Spot Light
is activated
Anti-flicker 50Hz/ 60Hz/ Off
When capturing LED lights that appear to
flicker, please enable this feature
according to the frequency.
Exposure Comp. On/ Off Turn on/off Exposure Comp.
Exposure Comp. Level -6~C~4
Adjustable after
Exposure Comp.
is
activated
Shutter Speed
60/30fps 50/25fps
Adjustable when the
Exposure mode
is
set to
Shutter Pri
or
Manual
1/10000~1/25
Iris Level F1.6~C~F14/ Close
Adjustable when the
Exposure mode
is
set to
IRIS Pri
or
Manual
Gain Limit 8~30dB Max. limit value of electron gain
Gain Level 0~30dB
Adjustable when the
Exposure mode
is
set to
Manual
WDR Off/ 1/ 2/ 3 WDR settings
White
Balance
Mode
1.Auto
2.Indoor
3.Outdoor
4.One Push WB
5.ATW
6.Manual
7.Sodium Lamp
Select the color temperature mode
1. 4000k ~ 7000k
2. 3200k
3. 5800k
4. 1700k ~ 10000k
5. 1700k ~ 10000k
6. Custom
7. 2800k
One Push Trigger ENTER One push trigger
Manual Red 0~C~127
Adjustable when the white balance mode
is set to
Manual
Manual Blue 0~C~127
Adjustable when the white balance mode
is set to
Manual
2D NR
Off/ 1/ 2/ 3 2D noise reduction
3D NR Off/ Low/ Typ/ Max 3D noise reduction
Image Mode Default/ Custom
The user may customize his/her desired
image mode
