English-16
ID/location
Please refer to 5.2.7 System - Output Setting
2
Preview window
Display the screen currently captured by the camera
3
Preset setting
Select the number first and then select SAVE or LOAD
4
Pan/Tilt setting
Adjust the Pan/Tilt position of the camera screen
5
Zoom
Zoom In/Zoom Out ratio
6
AF/MF
Switch AF/MF
7
Pan/ Tilt Speed
Adjust the horizontal/vertical moving speed of the lens
8
Zoom speed
Adjust the zoom speed
9
Camera Setting
Please refer to 5.2.3 Live Video - Camera Setting for related settings
10
Enlarge the
preview window
Zooming in/out the preview image
5.2.3 Live Video - Camera Setting
No
Item
Function Descriptions
1
Exposure
Mode: Select exposure mode (Full Auto/Shutter Pri/Iris Pri/Manual/White
Board)
Gain Limit: Adjust the gain limit (adjustable under “Manual”)
Exposure Comp. Level: Select exposure compensation level
WDR: Set the level of wide dynamic range (WDR) to obtain better images
Iris Level: Adjust the size of aperture (adjustable only under the “Manual” or
“Aperture Priority”
Shutter Speed: Adjust the shutter speed (adjustable only under the “Manual”
or “Shutter Priority”
Anti-Flicker: Enable Anti-flicker function(adjustable 50Hz or 60Hz)
2
White
Balance
Mode: Select the color temperature mode
Open Push WB: Single color temperature execution adjustment (adjustable
only under the “One Push WB”
Manual Red/Blue: Manually adjust blue/red color temperature
1
2
3
4
5
6
7
