INTERCONNECTION DIAGRAM

AUDIO OUT

AUDIO IN

N

I

E

D

U

A

S

A

M

+12 Vdc INPUT OUTPUT

AUDIO

BA C

MIC INPUT

VAN NUYS, CA

VERIFACT “A” MICROPHONE TO APR-1 BASE

STATION TO DVR, ETC.

Rear Panel of APR-1

REAR PANEL OF DVR WITH

RCA TYPE AUDIO INPUT

A B C

N

VERIFACT A

L

AD-1

AC Adapter

120V/12Vdc, 500mA

“Audio In” of APR-1

connects to “Audio Out”

of DVR or other receiving device

NOTE: If DVR’s audio input and output are 3.5mm (mini jack) type, use the appropriate adapter

at one end of RCA patch cable for connection. Check with manufacturer’s specifications

to determine if 3.5mm audio input/output is mono or stereo.

“Audio Out” of APR-1

connects to “Audio In”

of DVR or other receiving device

A

B

C

2 Conductor shielded cable, 22

gauge with a 24 gauge drain

wire.

NOTE: Unshielded cable is not

satisfactory for audio

systems.

WIRING REQUIREMENTS

INSTALLATION AND OPERATING INSTRUCTIONS

Terminal Block Identifier

for Microphone

(A) Red - 12Vdc power

(B) Black - Audio Output

(C) Bare - Ground

Page 4 of 8

LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX 994-6458

website: www.louroe.com e-mail: sales@louroe.com

(818)

®

ASK4_101_inst 12/14

®
