Basic Setup4
1. VGA cable (not included) — supports up to 1080p output.
2. HDMI cable (included)
• 4–channel DVRs: Supports up to 1080p output.
• 8/16–channel DVRs: Supports up to 4K output (4K monitor/TV required).
4.5 STEP 5: Connect to power
Connect the included power adapter to the 12V port. Connect the end of the power adapter to a
wall socket or surge protector. The DVR will power on.
1. Connect the included power cord to the rear panel as shown above.
2. Flip the ON/OFF switch to the ON position to power up the DVR.
NOTE
At startup, the system performs a basic system check and runs an initial loading sequence. After a few moments,
the system loads a live display view.
4.6 STEP 6: Upgrade firmware to latest version (if available)
If a firmware upgrade is available, you will be asked to install it once the DVR starts up. It is re-
quired to upgrade your system firmware and client software / mobile apps to the latest version to
enable remote connection to the system.
If a firmware upgrade is available:
#LX400086; r. 7.0/51608/56211; en-US 8
