10
Warning! Ensure the mounting surface supports
4.95 lbs (2.24 kg), 3× the camera’s weight.
E831SD
1. Use the mounting template to mark and drill holes for
screws and the camera’s cable.
2. Insert anchors for surfaces like drywall, wood, brick,
masonry, or concrete.
3. Attach the mounting bracket to the surface using the
provided screws and a screwdriver. Align the “FRONT”
labels on both the bracket and template.
4. Use a screwdriver to loosen the camera’s adjustment
screw, then remove the dome cover from the camera
base.
5. Guide the camera’s cable through the surface opening or
cable notch.
6. Connect one end of the Ethernet cable into the camera’s
Ethernet connector and the other end into the NVR’s PoE
port.
7. Angle your dome camera, then use a screwdriver to
tighten the dome cover rmly onto the camera base.
8. Important! Remove the vinyl lm from the camera lens.
EN - Camera Installation
