1.2 Assistance
The Lofrans products are backed throughout the world by a network of authorised distributors and assistance. In case of need,
please contact your local Lofrans distributor. Details on website www.lofrans.com
1.3 Receipt and Storage
Upon receipt of the package, verify the integrity of packing. Should it be necessary to store the product for a prolonged period,
keep it in a dry and protected place.
The Hand Held Control packaging includes:
Extra features:
• Normally open contacts
• Cable can be extended up to 4 meters
• Ergonomic case, soft nishing
4 INSTALLATION
33.3
33.3
Ø2.2x4
Ø20.5
L
E
N
Up
(Red)
Down
(Blue)
Common (Yellow)
20
(Fig. A)
(Fig. B)
Up/Red
Down/Blue
Common
-Yellow
1
(±1)
23
For mounting the female connector, drill on the dashboard one hole of 20.5 mm (~13/16”) and secure the female plug with the back
locking nut (Fig. A) to dashboard with a thickness not exceeding 10mm. Put the gasket between the rear part of the plug and the
dashboard. For instructions on making electrical connections, see the wiring diagram below (Fig.B).
2 TECHNICAL DATA
3 PACKAGING CONTENTS
Power Supply Up to 30V DC
Power consumption in standby 0 mA
Power consumption when in use 15 mA (12 V DC)
Operation temperature (°C) -10 / +60
Protection rating IP67
Dimensions (mm) 154 x 59 x 38
Weight (g) 120
USE ONLY ON DIRECT CURRENT WITH LOAD UP TO 2 AMPS / MUST BE USED WITH CONTACTORS OR A CONTROL BOX
This product is in
compliance with the
following regulations:
EN 55032: 2015
EN 55024: 2010+A1: 2015
1 Hand Held device-THETIS 1002
1 Cradle with 2 screws
1 Connector 3-pole (female plug)
1 Installation and user’s manual
Female
connector
Lofrans'
