15
www.lofrans.com
SX5
Item Description Q.ty
217 Hex hd screw M8x20 6
226 Washer for screw M8 14
231 Washer for screw M5 2
324 Hd cap screw - M8x20 10
250 Hd cap screw - M5x8 3
255 Key 6x6x25 1
260 Spring washer for screw M8 8
272 Handle 1
293 Hd cap screw - M5x16 2
336 Oil cap 1
361 Seal - 40x50x5 1
395 Seal - 50x70x10 2
396 Bearing - 16010 2
400 Circlip - 15 Din 471 4
407 Sightglass 1
414 Hex hd screw - M8x30 4
449 Pivot 2
453 Bearing - 6206 1
567 Clutch NuT 1
568 Seal - 55x72x10 1
575 Band brake 1
576 Pivot 1
577 Spring 1
578 Brake Pivot Wheel 1
581 Safety nut - M12 1
582 Dished plane spring 2
583 Clutch cone - inner 1
585 Brake pivot support 1
586 Brake pivot 1
609 Key 12x8x60 1
642 Brake cover 1
671 Bearing 6011 2
730 Conic screw M10x30 4
741 Key 12x8x150 1
746 Stud M8x40 4
874 Gearcase - upper 1
875 O Ring seal -4800 1
SX5
Item Description Q.ty
877 Racket 1
878 Gearcase - lower 1
879 O ring seal -159 2
880 Oil level ange 1
881 Coupling ange 1
883 Spacer 1
884 Handle 1
1024 Spring 1
1031 Sensor 1
1256 Electric Motor 3000W 24V 1
1260 Wormwheel 1
1261 Worm 1
1262 Motor ange for B14 1
1263 Hd cap screw M12x30 2
1264 Spacer 1
1265 Base 1
1269 Support sensor 1
1270 Hand-wheel 1
1272 Drum 1
1273 Clutch cone - outer 1
1275 Stripper 1
1276 Stripper base 1
1277 Seal - 55x90x10 1
1278 Spiral reating ring 55mm 2
1279 Circlip - 90 Din 472 2
1280 Main shaft 1
1313
Gipsy chain 12 iso - 13
Din766 - 1/2’’ Din766
1
1323 Key 6x7x40 1
574d Gipsy chain 14 iso 1
574g Gipsy chain 12.5 iso 1
632b Bearing - 51108 1
641ai A.C. Electric motor 4KW B14 1
2051 Gypsy cap sx5 L.P 1
2052 Upper cone clutch SX5 L.P 1
2053 Main shaft SX5 L.P 1
2054 Key SX5 L.P 1
UK
