6- INSTALLATION AND CONNECTIONS
1. Turn OFF the power supply to the thruster or the equipment being connected
2. Fit the receiver in a dry and accessible area (preferably not in the bilge). If necessary, use the 2 brackets supplied by
removing the 2 screws on the back of the receiver and replacing them with the 2 other screws supplied (M2.5 x 16). For a
thruster, an ideal location is behind one of the thruster control panels.
3. Connect the receiver to the power supply (12 or 24V DC)
4. CAUTION: ENSURE THE POLARITIES ARE RESPECTED. Reversing the polarity of the receiver WILL irreversibly
damage the receiver’s circuits.
5. Protect the positive supply cable of the receiver by means of a 1A fuse.
6. The receiver already has an integrated protection.
7. Connect the 4 outputs of the receiver (1, 2, 3 & 4) to the equipment that is to be operated. In the case of a bow thruster or
windlass, see the annexed diagrams for precise instructions.
8. NB: The outputs (1, 2, 3 & 4) are isolated volt free contacts with a load switching capacity of up to 24V and 5A
9. Follow the set up instructions (cf. chapter 7)
CAUTION:
Fit the receiver as far as possible from large metallic objects, electric motors or high current cables.
Please connect the radio receiver’s power supply to the yacht’s main service battery bank.
The battery bank powering the receiver must be suciently charged (refer to the battery supplier’s recommendations).
6
