LION 1000 - Cayman 88 - Tigres - Falkon
Dear Customer,
Thank you for choosing a Lofrans’ product. Lofrans’ is a leader company in the production and worldwide distribution of nautical systems
manufactured according to the most modern technologies, in compliance with international regulation requirements and the most
important certifying bodies. All our products are manufactured with excellent materials suited for operations in marine environments and
are subject to continuous checks to improve the qualitative levels and make them without any manufacturing defects. Together with such
requirements, Lofrans’ anchor windlasses are a synthesis of reliability and efciency, by guaranteeing the maximum performances during
each phase of mooring, even in the most difcult. With a Lofrans’ product, years of reliable operations are guaranteed.
Lofrans’ declines any liability for possible inaccuracies due to print errors in this manual and reserves the right to introduce any changes
deemed appropriate.
For this reason, Lofrans’ does not guarantee the accuracy of the manual after the date of issue and declines all liability for possible
errors and omissions.
1 INTRODUCTION 3
1.1 Purpose of the manual 3
1.2 Assistance 3
1.3 Receipt and storage 3
2 SAFETY INFORMATION 3
3 INSTALLATION 4
3.1 Contents of the package 4
3.2 Equipment necessary for installation 4
3.3 Recommended accessories 4
3.4 General requirements for installation 4
3.5 Prevention from electrolysis 5
3.6 Deck installation 5
4 ELECTRICAL SYSTEM 6
4.1 Electrical cable section 6
4.2 Solenoid valves (Control Box) 6
4.3 Circuit breakers 6
4.4 Remote control electric panel board 6
4.5 Protection of electrical components 6
4.6 Wiring diagram 7
5 USE OF THE WINDLASS 11
5.1 Lowering the anchor 11
5.1.1 Lowering the anchor Electrically 11
5.1.2 Lowering the anchor by gravity 11
5.2 Weighing the anchor 12
5.3 Use of the manual override 12
5.4 Use of the warping drum 12
5.5 Notes for use 13
Lofrans’©copyright, 2023. All rights reserved.
PRODUCT COMPLIANT WITH CE REGULATIONS
TABLE OF CONTENTS
6 MAINTENANCE 13
6.1 Maintenance programme 13
6.2 Gipsy maintenance/replacement 14
7 TROUBLESHOOTING 14
8 TECHNICAL DATA 17
9 SPARE PARTS 19
10 OVERALL DIMENSIONS 27
11 WARRANTY CONDITIONS 31
11.1 Conditions and limits 31
11.2 Exceptions 31
11.3 Liability 31
11.4 Procedure 31
11.5 Clause of Termination 31
11.6 Compliance 31
