Je bekijkt pagina 15 van 308

15



Loewe radio.frequency

english

2 Main unit components

2.1 Top side

1 Power button – Long press to power the

radio on or off. When the radio is on, a short

press puts the radio in standby mode. When

the radio is in standby mode, press briefly

to switch it on.

2 Source – Press to change input source.

Toggle between DAB, FM and Bluetooth

mode.

3 Alarm – Enter alarm settings.

4 Preset buttons – In radio mode: press

shortly to recall favourite radio station.

Press and hold to store current radio sta-

tion.

5

– In DAB radio mode: short press to

switch to previous saved station.

In FM radio mode: short press to switch to

the previous saved station. Long press to

scan for a station with lower frequency.

In Bluetooth mode: skip to previous track.

6

– In DAB radio mode: short press to

switch to next saved station.

In FM radio mode: short press to switch to

the next saved station. Long press to scan

for a station with higher frequency.

In Bluetooth mode: skip to next track.

7 Info – Toggle information shown on the

display.

8 Menu – Enter settings menu.

9 Back – Step back in the menu or exit menu.

10 Volume knob

In radio mode: press to mute/unmute.

In Bluetooth mode: press to play/pause.

All sources: Rotate clockwise to increase

volume level.

Rotate counterclockwise to decrease vol-

ume level.

While in menu: Press to enter submenu or

confirm selection.

Rotate to navigate between menu items.

2.2 Front side

LCD Display

2.3 Back side

1. Telescopic antenna

2. USB-C input – connect USB PD power

supply. The PD adapter will provide 9V to

recharge the battery.

3. 3,5mm earphones output

4. Kensington Lock

1 2 3 4 5 6 7 8 9

10

2 3 41

Main unit components
