Battery Safety Instructions
19. Disposing of a battery in fire or a hot oven, or mechanically crushing or cutting a battery, may
result in an explosion.
20. Extreme temperatures to which the batteries may be exposed during use, storage, or transport:
• During use: 0°C to 45°C
• During storage: -10°C to 45°C
• During transport: -10°C to 45°C
21. Leaving a battery in an environment with extremely high temperatures may cause an explosion or
the leakage of flammable liquid or gas.
22. A battery subjected to extremely low air pressure may cause an explosion or the leakage of
flammable liquid or gas.
Technical Specifications
Bluetooth compatible speaker
Input: DC 5V - 1A
Signal-to-noise ratio: 60db
Battery input: Li-ion 3.7V DC - 500mAH
Speaker impedance: 4Ω
Bluetooth version: V5.3
Speaker power: 5W
Frequency: 2402MHz-2480MHz
Range up to 10m
Maximum music playback time: 7Hrs
Maximum transmit power: 0.79dBm
Charging time: 3 hours
Drawing of the device
Figure 1
1
Front panel
6
USB C input
2
Speaker
7
Auxiliary input
3
On / Pause
8
Microphone
4
Previous / Volume -
9
Hand strap
5
Next / Volume +
10
USB A to USB-C charging cable
Operation Instruction
Charging the device
Fully charge the device before using it. Insert the USB-C cable into the dedicated port. Connect the USB
port to another device which is able to charge your device. Be sure to respect the maximum charging
voltage mentioned on the device (5V) to avoid damaging it. The speaker's indicator light turns on during
charging. When the battery is fully charged, the light goes off.
Note: Charge the device at least once every 3 months when not in use for an extended period to prevent
potential damage to the battery.
Bluetooth function Connection
Disable the Bluetooth function when not in use. Enable Bluetooth settings on your mobile phone and
search for the TES266 device. Open the music player on your device and start listening to music.
Using the Bluetooth compatible Speaker
To power On/Off the device, long press the power button.
