17 GB/IE
Before use
Note: Remove all packaging materials from the product.
Installation
Mounting the product
on wooden wall
Move the cover
3
upward (Fig. A).
Use the mounting bracket
4
and screws
5
to
mount the product.
Hold the mounting bracket
4
against the desired
surface and mark the drill holes (Fig. A). Now drill
the mounting holes (ø approx. 2 mm, approx.
17 mm deep).
Position the mounting bracket
4
according to the
predrilled holes and tighten the screws
5
by a
cross tip screwdriver (Fig. A).
The lamp arm can be fixed, if desired. To do so,
tighten the two locking screws
6
on the swivel joint.
Move the cover
3
downward.
Connect the low voltage plug connection
9
with
the LED driver
10
(Fig. C).
Mount the LED driver
10
using the included screws
11
(Fig. C).
Plug the mains plug
13
into the mains socket.
Your product is now ready to use.
Mounting the product
on concrete wall
Move the cover
3
upward (Fig. B).
Use the mounting bracket
4
, screws
8
and the
wall plugs
7
for wall mounting.
Hold the mounting bracket
4
against the desired
surface and mark the drill holes (Fig. B). Now drill
the mounting holes (ø 6 mm, approx. 30 mm deep).
CAUTION! Ensure that you do not damage any
electrical cables, gas or water pipes when you
drill into the wall.
Insert the included wall plugs
7
into the bores.
Position the mounting bracket
4
according to the
predrilled holes, insert the screws
8
into the wall
plugs
7
, and tighten the screws
8
by a cross tip
screwdriver (Fig. B).
The lamp arm can be fixed, if desired. To do so,
tighten the two locking screws
6
on the swivel joint.
Move the cover
3
downward.
Connect the low voltage plug connection
9
with
the LED driver
10
(Fig. C).
Mount the LED driver
10
using the included screws
11
(Fig. C).
Plug the mains plug
13
into the mains socket.
Your product is now ready to use.
