Je bekijkt pagina 13 van 16
14 GB
Changing the bulb / Maintenance and cleaning / Disposal / InformationSafety / Preparation / Mounting the light / Initial use / Changing the bulb
Never use the light if you are having difficulty
concentrating or do not feel well.
Familiarise yourself with all instructions and di-
agrams in this manual as well as with the light
itself before use.
Preparation
Required tools and material
The tools and materials specified are not included.
This information and these values are non-binding
and are only provided as a reference. The nature
of the material is determined by the individual local
conditions.
- Pencil / marking tool
- Voltage tester
- Screwdriver
- Electric drill
- Drill (approx. ø 6 mm)
- Side cutting pliers
- Ladder
Mounting the light
RISK OF ELECTRIC SHOCK!
Prior to installation, remove the fuse or switch off he
circuit breaker in the fuse box (Position 0).
Remove the locating screws
3
visible at the
side of the terminal housing
8
and remove
the mounting bracket
2
at the back.
Use the slotted holes for the screws
4
on the
mounting bracket
2
to mark the bores. Now
drill the mounting holes (approx. 6 mm, depth
approx. 30 mm). Be sure not to damage the
supply line.
Insert the wall plugs
1
into the drilled holes.
Fasten the mounting bracket
2
with the pro-
vided screws
4
.
Pull the protective tubes
5
over cables L and
N of the mains connection cord (external)
6
.
Note: Be sure to correctly connect the individual
leads on the mains connection cord (external)
6
:
live wire, black or brown = symbol L, neutral
wire, blue = symbol N, earth wire, green-yellow
= symbol
.
Now use the locating screws
3
to connect the
light to the mounting bracket
2
.
Use a clean, lint-free cloth to insert the light
bulb
12
.
Screw the light bulb
12
clockwise into the
socket
11
.
Verify it is seated correctly.
Press two of the spring clips
10
into the opening
of the lamp shade
13
.
Slide the lamp disk
9
somewhat in the direction
of the already inserted spring clips
10
.
Now press the third spring clip
10
far enough
downwards for you to press it into the opening
of the lamp shade
13
with little difficulty.
Bring the lamp disk
9
into a central position
over the opening of the lamp shade
13
.
Reinsert the fuse or switch the circuit breaker
back on.
Your light is now ready to use.
Initial use
Use the wall switch to switch the light on or off.
Changing the bulb
RISK OF ELECTRIC SHOCK!
When replacing the illuminant, first connect the light
from the mains. To do so, remove the fuse or switch
off the circuit breaker in the fuse box 0 position.
CAUTION! RISK OF BURNS DUE TO HOT
SURFACES!
Allow the light to cool completely.
Only replace the illuminant
12
after it has fully
cooled.
Use a clean, lint-free cloth when replacing the
illuminant
12
.
Note: Hold the lamp disk
9
tightly while you
are removing the lamp shade
13
.
Push the lamp disk
9
somewhat aside.
Pull the lamp shade
13
downwards from the
spring clips
10
.
