14 GB/IE
18
Seal ring
19
TIME rotary control
20
LUX rotary control
Technical data
Operating voltage: 230 V∼ 50 Hz
Total power consumption: 18 W
Illuminant: 30 x 0.5 W LED
(non-replaceable)
Twilight-switch: adjustable between
10 lx – 20,000 lx
Lighting duration: adjustable between
approx. 10s +/- 5s –
4min +/- 1min
Coverage angle of
motion detector: approx.180°
horizontal
Reach of the
motion detector: maximum 10 m
Protection class: I
Degree of protection: IP44 (splash-proof)
Overall dimension: 15.5 x 17.5 x 14.5 cm
Weight: approx. 460g
(includes accessories)
Projected area: max. 15.5 x 17.5 cm
Mounting height: approx. 1.8–2.5 m
TÜV SÜD / GS certified.
Scope of delivery
Check immediately after unpacking that the parts
are complete and that the product is in proper
condition.
1 LED spotlight with motion detector
2 Wall plugs (Ø 8 mm)
2 Screws (Ø 5 mm x 50 mm)
1 Mounting bracket
1 Cord anchorage
2 Tooth lock washers
2 Flat washers
2 Spring washers
2 Locking screws
1 Instructions for use
General safety
instructions
BEFORE USING THE PRODUCT, PLEASE FA-
MILIARISE YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND INSTRUCTIONS
FOR USE! WHEN PASSING THIS PRODUCT
ON TO OTHERS, PLEASE ALSO INCLUDE ALL
THE DOCUMENTS!
DANGER TO LIFE AND
ACCIDENT HAZARD FOR
TODDLERS AND SMALL
CHILDREN! Never leave children unattended
with the packaging material. The packaging
material represents a danger of suffocation.
Children frequently underestimate the
