21 GB/IE
transport from the manufacturer to the retail location. Therefore,
please charge the rechargeable battery before the first use.
Slide the ON / OFF switch
11
to the ON position.
Note: In constant sunlight (depending on the season) a drained
rechargeable battery should take two to ten days to charge.
Note: The built-in charging controller of the LED solar spotlight
prevents the rechargeable batteries from overcharging. Replace
the rechargeable battery if the light output does not improve after
charging (see “Replacing the rechargeable battery“).
Initial use
Note: The solar cell
6
also works as a twilight sensor, while the
motion sensor
7
only responds to movement.
When selecting the setup location for the solar cell
6
ensure
that the solar cell, as well as the twilight sensor, is not affected
by other light sources, e.g. street lighting.
The “ON“ position for the ON / OFF switch
11
features
the following functions:
If the orientation light is constantly lit up, it will automatically switch
on or off once the solar cell
6
detects dusk or dawn. To ensure a
long operating life, the LEDs will not be fully powered in this setting,
but only provide approx. 15 lm. If the rechargeable battery is fully
charged, the charge will be sufficient for approx. 8 hours of lighting.
As soon as the motion sensor
7
detects movement, the product
will switch to particularly bright light. While the particularly bright
light is switched on, the LEDS will be run at full power and supply
approx. 200 lm. Approx. 40 seconds after the last movement has
been detected, the product will return to functioning as a constantly
lit-up orientation light.
Installation
When selecting the mounting location, pay attention to the
following:
1. The solar cell
6
requires direct sunlight when possible. Ideally,
the solar cell surface will be directed to the south. The horizon-
tal direction of the solar cell is dependent on mounting on a
vertical wall.
2. Depending on the mounting height (ideally at 2 m) the sensor
7
has a detection range of max. 5 m with a detection angle of 9
0 °
horizontally and 90 ° vertically.
