16 GB/IE
WEAR PROTECTIVE GLOVES!
Leaked or damaged rechargeable
batteries could cause chemical
burns on contact with the skin; you should
therefore wear suitable protective gloves at all
times if such an event occurs.
Only use rechargeable batteries of the correct
size and and the recommended type (see sec-
tion ”Technical Data”).
Ensure correct polarity, indicated in the battery
compartment.
Functionality
The solar cell built into the product converts sunlight
into electricity and stores it in a Ni-MH rechargea-
ble battery. The light switches on at dusk. The built-
in LED is an energy-saving light bulb with a very
long life. The light duration depends on the amount
of sunlight, the angle at which light hits the solar
panel, and the temperature (the battery capacity
varies by temperature). A vertical angle of light at
temperatures above the freezing point is ideal. The
rechargeable battery will only achieve its maximum
capacity after several charging and discharging
cycles.
Initial use
Mounting the light
10346A/B:
Pull the solar cell housing
2
including
lampshade
1
out of the lamp body
3
.
Push the ground stake
4
out of the adapter
5
and into the lamp body
3
.
Push the ground stake
4
into the ground in
the desired location and attach the lamp
body
3
.
Set the ON/OFF switch
7
to the position
marked „ON“ to allow the product to switch
on in the dark.
Reattach the solar cell housing
2
with lamp
shade
1
to the lamp body
3
. Your solar
light is now ready to use.
10346C/D:
Pull the solar cell housing
2
including lamp-
shade
1
out of the lamp body
3
.
Push the ground stake
4
out of the adapter
5
and into the lamp body
3
.
Push the ground stake
4
into the ground in
the desired location and attach the lamp
body
3
.
Turn the solar cell housing
2
out of the lamp-
shade
1
counter-clockwise.
Set the ON/OFF switch
7
to the position
marked „ON“ to allow the product to switch
on in the dark.
Insert the solar cell housing
2
into the lamp-
shade
1
and tighten clockwise. Your solar
light is now ready to use.
10346E/F:
Pull the solar cell housing
2
off the lamp
shade
1
.
Set the ON/OFF switch
7
to the position
marked „ON“ to allow the product to switch
on in the dark.
Reattach the solar cell housing
2
to the lamp
shade
1
. Your solar light is now ready to use.
Installing the light
10346A / B / C / D:
Push the ground stake
4
far enough into the
ground (lawn, flower bed) so it is firmly posi-
tioned upright in the ground. Then attach the
assembled solar light to the ground spike
4
.
Make sure it is firmly positioned. Do not use
force when assembling or setting up the prod-
uct, e.g. hammer blows. This will damage the
product. In order to achieve the best result, set
the solar garden lamp up in a place where the
solar cell will get direct sunlight for as long as
possible.
Make sure the solar cell is not impacted by
other light sources, e.g. yard or
street lighting,
or the light will not
switch on at dusk.
The light will automatically switch on in low
light and switch off in normal daylight.
