10
Adjust Mix Level
Adjust the mix level until the right VU meter occasionally illuminates the red LED. This is the level
adjustment for the combined output from Input 1 and Input 2.
If you are using another manufacturers’ receivers with the LT-800/LT-803, determine the frequency of their
receivers then refer to Listen’s Frequency Compatibility Tables (pages 14-15) to find the Listen channel that
corresponds with the receiver’s frequency. We recommend verifying corresponding channel designations
on these tables to ensure compatibility and provide the best possible reception.
The LT-800-216 is Phonak compatible and can be set to display Phonak specific channels. See page 7 to set
Channel Mode and page 13 for specific channel designations.
Adjust Audio Input Level
Adjust the input knob counterclockwise to add gain to Input 1. This will decrease gain to Input 2. Adjust
input knob clockwise to add gain to Input 2. This will decrease gain to Input 1. If you have two audio
sources connected to both Input 1 and 2, adjust the level of one input using the VU meter, then adjust
the output level of the other audio source. Adjust the input level until the left VU meter(s) occasionally
illuminate the red LEDs. Illumination of the red LEDs indicates the unit is in limiting. Limiting is required so
that the unit does not over-modulate the transmitter. If you don’t want any audio limiting to occur, make
sure the red LEDs never illuminate. If you want a highly limited signal, turn the audio gain up so the red
LEDs illuminate often.
Adjust Contour
Adjust the Contour knob counterclockwise if your audio source is mostly voice. Adjust the knob clockwise
if your audio source is mostly music. The Contour knob adjusts the relative equalization of the unit. This
equalization boosts or cuts frequencies above 5 kHz.
Audio Control
1
2
3
