English - 20 -
smoother and faster HD video streaming, file
transfers, and wireless gaming.
• Use a LAN connection for quicker file sharing
between other devices like computers.
• The frequency and channel differ depending on
the area.
• The transmission speed differs depending on the
distance and number of obstructions between the
transmission products, the conguration of these
products, the radio wave conditions, the line trafc,
and the products that you use. The transmission may
also be cut off or may get disconnected depending
on the radio wave conditions, DECT phones, or any
other WiFi 11b appliances. The standard values of
the transmission speed are the theoretical maximum
values for the wireless standards. They are not the
actual speeds of data transmission.
• The location where the transmission is most effective
differs depending on the usage environment.
• The Wireless LAN adaptor should be connected
directly to the TV’s USB port. USB hubs are not
supported.
• To congure wireless settings please refer to the
WiFi section in the Settings menu.
• You can plug your wi dongle into the supplied USB
extension cable In cases where network quality is
poor and the wi dongle needs to be placed to a
location with better signal quality.
• Wireless LAN adaptor supports 802.11 a,b,g &
n type modems. It is highly recommended that
you should use the IEEE 802.11n communication
protocol in order to avoid any possible problems
while watching videos.
• Use the other USB input, if you experience problems
with audio/video performance.
• You must change your modem’s SSID when there
are any other modems around with the same SSID.
You can encounter connection problems otherwise.
Use a wired connection if you experience problems
with a wireless connection.
To enable Wi-Fi features, plug in the Wi-Fi dongle to
one of the USB ports.
Press the YELLOW button to scan the wireless
networks from the network settings menu. A list of
available networks will be displayed. Please select
your desired network from the list.
If the selected network is protected with a password,
please enter the correct key by using the virtual
keyboard. You can use this keyboard via the
navigationbuttons ( “ ” or “ ”, “ ” or “ ”) and
the OK button on the remote control.
Wait until the IP address is shown on the screen.
Press the GREEN button to switch to advanced
mode and then press the OK button to edit settings.
This means that the connection is now established.
To disconnect from a wireless network, you should
highlight CongurationStatus and press OK.
You can navigate between menu tabs by pressing
left/right buttons. The help bar on the bottom of the
dialog shows features that you may use. Press the
BLUE button to check your internet connection speed.
You can check the signal strength by using the network
settings menu for the wireless device mode.
OtherInformation
Configuration Status: Displays Wi-Fi status as
connected or not connected.
IPAddress: Displays the current IP address.
NetworkName: Connected networks’ name will be
displayed.
DeleteSavedWiFiProles
Saved proles will be deleted if you press the Red
button while the wireless device selection OSD is
on the screen.
