10 Part Number 20000095 Rev J 5/15
Installation Section 2
Specifications
Electrical Service — All Gas Models
Voltage (AC) Phase Hz
Model 3240/3255
Amps
Model 3270
Amps
Single Oven 120 1 60 6.0 14.0
Double Stack 120 1 60 12.0 28.0
Triple Stack 120 1 60 18.0 42.0
International Ovens
(Single Stack)
230/240 1 50 3.15 7.3
General Information – 3240 Natural Gas Ovens
Model Energy Power Voltage Current Phase Hz
Gas Supply
Pressure
Gas Pipe Size
(NPT)
Single Oven Nat. Gas 115,000 BTU 120 VAC 6 Amps 1 60 Hz 8 – 14" W.C. 1"
Double Stack Nat. Gas 230,000 BTU 120 VAC 12 Amps 1 60 Hz 8 – 14" W.C. 1-1/4"
Triple Stack Nat. Gas 345,000 BTU 120 VAC 18 Amps 1 60 Hz 8 – 14" W.C. 1-1/2"
Single Oven Nat. Gas
G20
31 kW (HI)
144 MS/hr
3.88 m
3
/hr
230 VAC 3.15 Amps 1 50 Hz 2.00 - 3.48 kPa 1"
Single Oven Nat. Gas
G25
26 kW (HI) 230 VAC 3.15 Amps 1 50 Hz 2.00 - 3.48 kPa 1"
General Information – 3240 Propane Gas Ovens
Model Energy Power Voltage Current Phase Hz
Gas Supply
Pressure
Gas Pipe Size
(NPT)
Single Oven L.P. Gas 115,000 BTU 120 VAC 6 Amps 1 60 Hz 11.5 – 14" W.C. 3/4"
Double Stack L.P. Gas 230,000 BTU 120 VAC 12 Amps 1 60 Hz 11.5 – 14" W.C. 1"
Triple Stack L.P. Gas 345,000 BTU 120 VAC 18 Amps 1 60 Hz 11.5 – 14" W.C. 1-1/4"
Single Oven L.P. Gas
G30
37 kW (HI)
2.315 kg/hr
230 VAC 3.15 Amps 1 50 Hz 2.85 – 3.48 kPa 3/4"
Single Oven L.P. Gas
G31
31 kW (HI)
144 MS/hr
1.14 m
3
/hr
2.545 kg/hr
230 VAC 3.15 Amps 1 50 Hz 2.85 – 3.48 kPa 3/4"
General Information – 3240 Electric Ovens
Model Energy Power Voltage Current Phase Hz
Recommended Electrical
Specifications
3240-XXX-B-KXXXX Electric 24kW 400/230 Vac 35 Amps 3 50 Hz 5 Wires, 3 Poles 1N-1G
3240-OXX-R-KXXXX Electric 24kW 120/208 Vac 67 Amps 3 60 Hz 4 Wires, 3 Poles -1G
3240-OXX-V-KXXXX Electric 24kW 120/240 Vac 58 Amps 3 60 Hz 4 Wires, 3 Poles -1G
3240-XXX-D-KXXXX Electric 24kW 380Y/220 Vac 37 Amps 3 50 Hz 5 Wires, 3 Poles 1N-1G
3240-XXX-G-KXXXX Electric 24kW 415Y/240 Vac 34 Amps 3 50 Hz 5 Wires, 3 Poles 1N-1G
