C-1

OPTIONS/ACCESSORIES

The following options/accessories are available for your

Fume Extraction Arms from your local Lincoln Electric Distributor.

FUME EXTRACTION ARMS

ACCESSORIES

Kit allows mounting of Prism 2400 fan and

extraction arm to wall. Use for Flexible 7FT,

Telescopic 5FT and Low Ceiling 13FT

extraction arms.

K1657-2 PRISM 2400 WALL MOUNTING

BRACKET FOR TELESCOPIC 5 FT., FLEXIBLE

7 FT. & LOW CEILING 13 FT. ARM

K1669-4

LAMP KIT WITH ARC SENSOR (PRISM 2400 FAN)

Mounted in the lamp housing, the arc sensor

turns the fan on when sensing the arc flash,

and turns off 50 seconds after the arc extin-

guishes. Hood mounted switches turn the unit

on and off independently of the arc sensor. Kit

includes lamp housing with arc sensor,

control box, interconnect wire, hood mounted

lamp/ fan switch and instruction manual.

Required for Prism® Wall Mount. For Prism

2400 Fan, use K1669-4. For Prism 4200 Fan,

use K1669-10.

K1669-10

LAMP KIT WITH ARC SENSOR (PRISM 4200 FAN)

K1657-5 CONNECTOR, 8 IN. DUCT TO

EXTRACTION ARM.

Allows 8” duct work to be attached to all

arms except K1655-10 and Prism

Mobile

arms K2633-5, K2633-6, K2633-7 and

K2633-8.
