LIGHT4ME DMX 192 v2
Instrukcja obsługi / User Manual
19
Panel instruction
18) Blackout – Output black keys. Pressing the button makes light bright. When the control output value
of platform at all channels is 0, the result are black scenes.
19) Music - Voice-activated key. Pressing the button makes light bright. Running the program is trig-
gered by the built-in microphone.
20) Scene Edit / Run - Scene Editor / run key. When pressing time is more than 1 second, the indicator
light flashes into the scene editor state. When pressing for 1 second again, it withdraws from editing
the state to the running state. Bright light is always on.
21) Chase Edit / Run - Walking light program editor / run key. When pressing time is more than 1
second, the indicator light flashes into the scene editor state. When pressing for 1 second again, it
withdraws from editing the state to the running state. Bright light is always on.
22) Manual - Control key.
23) Page1 - Access keys page 1.
24) Page2 - Access keys page 2.
25) Ch1/Ch9-Ch8/Ch16 - Channel fader (page one 1-8 / page two 9-16).
26) 1-12 - The number keys 1-12. Used to select the No. field, and follow procedures and signal lights
to choose.
27) Step - A key (run). Operation to remove lantern; (edit scenes) deleted scenes; (Edit the walking
light procedure) Step Remove Programs / Remove Programs / decreasing step-by-step selection
procedure.
28) Step - B key (edit scenes). scene copy / preserve the scene; (Editor lights go procedure) incre-
mental step-by-step selection procedure.
29) Scene - C key (Scene Editor / walking lights Procedure). Its reduced choice key of scenes.
30) Scene - D key (Scene Editor / walking lights Procedure). Its increases choice key of scenes.
31) Digital display.
32) Speed - Speed adjustment fader.
33) Cross - Gradual adjustment fader.
34) Power - Power switch.
