w
Display shows reminder information.
u
Briefly touch the display
u
Check the water connection.
-or-
u
Deactivate IceMaker. (see Deactivating the IceMaker /
MaxIce )
If water connection is checked and IceMaker is activated:
u
Clean the IceMaker. (see 9.4.6 Cleaning the IceMaker)
w
IceMaker produces ice cubes.
Insert the IceMaker drawer
Fig. 90 Example illustration
u
Briefly touch the display.
w
Display shows reminder information.
u
Briefly touch the display.
u
Insert the IceMaker drawer.
-or-
u
Deactivate IceMaker. (see IceMaker / MaxIce )
w
If IceMaker drawer is inserted and IceMaker is activated:
IceMaker produces ice cubes.
Replace the FreshAir activated carbon filter
Liebherr recommends: Replace the FreshAir activated
carbon filter every 6 months.
Note
FreshAir activated charcoal filters can be purchased
from the Liebherr-Hausgeräte store at home.liebherr.com/
shop/de/deu/zubehor.html.
Fig. 91 Example illustration
u
Briefly touch the display.
w
Display shows reminder information.
u
Briefly touch the display.
u
Replace the activated carbon filter. (see 9.1 Air exchange
through the FreshAir activated charcoal filter)
w
Activated carbon filter ensures optimum air quality in the
cooling unit.
w
Reminder appears again after 6 months.
If you no longer wish to receive this reminder, you can deac‐
tivate it. (see Deactivating the reminder)
8 Features
8.1 Drawers
You can remove the drawers for cleaning.
You can remove the drawers to use VarioSpace.
The way to remove/insert the drawers varies depending
on the pull-out system. Your appliance can contain various
pull-out systems.
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
u
Leave the bottom drawer in the appliance!
u
Always leave the fan air vents clear on the back wall!
8.1.1 Drawer on telescopic rails
The drawer runs on extendible rails (telescopic rails). There
are fully extendible telescopic rails and telescopic rails with
partial pull-out. Drawers which are fully extendible can be
pulled out fully from the appliance. Drawers with partial
pull-out cannot be removed fully from the appliance. The
system in your appliance depends on the type of appliance.
Partial pull-out freezer compartment
Note
If the magnet on the top drawer in the freezer compartment
is damaged or removed, the door sensors will malfunction.
u
Do not damage or remove the magnet.
Removing drawer
Fig.92
If the drawer is in the top freezer:
u
Pull out drawer as far as it will go.
u
Raise the drawer forwards.
u
Remove the drawer forwards.
u
Slide rails in.
-or-
Fig. 93
If the drawer is in the middle part of the freezer compart‐
ment:
u
Pull out drawer half-way.
u
Lift the drawer from the bottom rear.
u
Remove the drawer forwards.
u
Slide rails in.
Inserting drawer
Fig. 94
u
Slide rails in.
u
Guide drawer around the stoppers Fig. 94(1).
u
Place drawer on rails.
u
Slide in drawer to the back.
Features
* Depending on model and options 21
