4.2 Appliance dimensions
Fig. 6 Example illustration
(A)
Device height
including feet/rollers
(C) Device depth without
handle [handle
depth = 45 mm (1 6/8in)]
(B) Device width without
handle [handle
depth=45mm
(1 6/8in)]
(D) Device depth with door
open
A 819mm
B 597mm
C
605mm
x
D
1162mm
x
x
On devices with attached wall spacer brackets, this dimen‐
sion increases by 35mm.
4.3 Transporting appliance
WARNING
Risk of injury due to broken glass!*
When transporting at an altitude of more than 1500 m, the
glass panes of the door may break. This can result in sharp-
edged fragments, which can cause serious injuries.
u
Take appropriate protective action.
Note when transporting the appliance:
u
Transport the appliance upright.
u
Use two people to transport the appliance.
During first use:
u
Transport the appliance packaged.
When transporting appliances after initial commissioning
(e. g. moving or cleaning):
u
Empty the appliance.
u
Secure the door against unintentional opening.
4.4 Unpacking appliance
u
Check the appliance and the packaging for damage
during transport. Contact the supplier immediately if you
suspect any damage. Do not connect appliance to the
power supply.
u
Remove all packaging materials from the rear or the side
walls of the fridge that may prevent proper installation or
prevent air flow and ventilation.
4.5 Installing door handle
Fig.7
u
Attach handle from accessory kit to the door using the
screws Fig.7(1) supplied.
u
Put on cover Fig.7(2).
u
Insert the plug from the accessory pack on the opposite
side. *
4.6 Installing appliance
CAUTION
Risk of injury and damage.
u
Use 2 people to install appliance.
CAUTION
Risk of injury and damage.
The door can knock against the wall and become damaged
as a result. In the case of glass doors, the damaged glass
can cause injuries.
u
Protect the door from knocking against the wall. Attach
door stopper, e.g. felt stopper, to the wall.
u
Connect all necessary components (e.g. mains cable) to
the back of the appliance and route to the side.
Note
Cables can be damaged.
u
Do not jam the cable when pushing the appliance back.
4.7 Setting up the appliance so it is
level
NOTICE
Appliance body is deformed and door does not close.
u
Align appliance horizontally and vertically.
u
Compensate for uneven floors using adjustable feet.
WARNING
Incorrect height adjustment of the adjustable foot!
Can cause severe or even fatal injury. Incorrect height
adjustment can cause the bottom part of the adjustable
foot to come loose and the appliance to tip over.
u
Do not unscrew the adjustable foot too far.
Putting into operation
8 * Depending on model and options
