The symbol is located on the back of

the appliance near the alarm relay and

indicates the following danger: Electric

shock! Even if an appliance is discon‐

nected from the mains there may still be

extraneous voltage. Do not remove sticker.

This or a similar sticker may be located

on the rear of the appliance. This sticker

indicates that there are vacuum insulation

panels (VIP) or perlite panels in the door

and/or housing. This advice is only relevant

to recycling. Do not remove the sticker.

This or a similar sticker may be located on

the rear of the appliance. It refers to the

Li-ion self-charging battery installed. This

advice is only relevant to recycling. Do not

remove sticker.

Please note the warning messages and other

specific advice in the other chapters:

DANGER

Indicates an immediately

hazardous situation which will lead

to death or serious injuries if it is

not avoided.

WARNING

Indicates a hazardous situation

which will lead to death or serious

injuries if it is not avoided.

CAUTION

Indicates a hazardous situation

which will lead to minor or

moderate injuries if it is not

avoided.

NOTICE

Indicates a hazardous situation

which may lead to damage to prop‐

erty if it is not avoided.

Note

Indicates useful instructions and

tips.

3 Functionality of the

Touch&Swipe display

You operate your appliance using the Touch & Swipe display.

You select appliance functions in the Touch & Swipe display

(hereafter referred to as display) by tapping them. If you

do not perform any action on the display for 10 seconds,

the display either jumps back to the higher-level menu or

directly to the status display.

3.1 Navigation and symbol explanation

In the illustrations, different symbols are used to navigate

the display. The following table describes these symbols.

Symbol

Description

Briefly touch the display:

Activates/deactivates function.

Confirms selection.

Opens submenu.

Symbol Description

Touch the display for a specified time

(e.g. 3seconds):

Activates/deactivates function or

value.

Swipe left or right:

Navigate in the menu.

Briefly touch the Back symbol:

Jumps back one menu level.

Press and hold the Back symbol for

3seconds:

Jumps back to the status display.

Briefly touch the Back symbol at the

top left:

Jumps back one menu level.

Arrow with clock:

It takes more than 10 seconds for the

following message to appear in the

display.

Arrow with a time indication:

It takes the specified amount of time

until the following message appears in

the display.

“Open Settings menu” symbol:

Navigates to the Settings menu and

opens the settings menu.

If necessary: Navigate to the desired

function in the Settings menu.

(see 3.2.1 Opening the Settings menu)

“Open Advanced menu” symbol:

Navigates to the Advanced menu and

opens the advanced menu.

If necessary: Navigate to the desired

function in the Advanced menu.

(see 3.2.2 Opening the expanded

menu)

No action for

10seconds

If you do not perform any action on

the display for 10 seconds, the display

either jumps back to the higher-level

menu or directly to the status display.

Open door and

close it again.

If you open the door and immedi‐

ately close it again, the display jumps

directly back to the status display.

Note: Illustrations of the display are shown in the English

version.

3.2 Menus

The appliance functions are distributed over various menus:

Functionality of the Touch&Swipe display

6 * Depending on model and options
