Fig.36
u
Turn the bearing socket by 180° and press it into the
underside.
Fig.37
u
Detach the locking bracket.
Fig.38
u
Turn the locking bracket 180° and fit it on the opposite
side.
Fig. 39
u
Attach the hinge.
4.11.15 Converting the bottom hinge
NOTICE
Danger of injury due to tensioned spring!
u
Do not dismantle the screw connection Fig. 40 (1) on the
locking system.
Fig.40
u
Turn the locking system Fig.40(2) until it clicks.
w
The locking system pre-tension is released.
Fig. 41
u
Detach the hinge bracket.
Putting into operation
* Depending on model and options 15
