4.1.1 Setup location

WARNING

Leaking refrigerant and oil!

Fire. The refrigerant contained within the appliance is

environmentally friendly, but flammable. The oil

contained within the appliance is flammable. Escaping

refrigerant and oil can ignite if they are of high enough

concentration and are exposed to an external heat

source.

Do not damage the pipelines of the coolant circuit

and the compressor.

Do not setup the appliance in direct sunlight, next to

an oven, radiator or similar.

The best place to set up the appliance is a dry and

well ventilated room.

If the appliance is set up in a very humid environ‐

ment, condensation can form on the outside of the

appliance.

Always ensure sufficient airflow and ventilation in

the setup location.

The more refrigerant there is in the appliance, the

larger the space it is installed in must be. If the

space is too small, any leak may create a flammable

mixture of gas and air. For every 8 g (0.28 oz) of

refrigerant, the installation space must be at least

1m

(35.5ft

). Specifications on the refrigerant in the

appliance can be found on the serial tag plate inside

the appliance.

The floor of the setup location must be horizontal

and even.

The setup location must be able to withstand the

weight of the appliance plus the weight when

stocked to maximum capacity. (see 9.1 Technical

data)

Use in hazardous areas is not permitted.

4.1.2 Electrical connection

WARNING

Danger of fire due to incorrect positioning!

If the power supply cable or plug touches the back of

the appliance, the vibration can damage the power

supply cable or the plug resulting in a short circuit.

Make sure the power supply cable is not trapped

under the appliance when you position the appli‐

ance.

Install the appliance so that it does not touch any

plugs or power cables.

Do not connect any appliances to sockets in the area

of the back of the appliance.

Do not place and operate power strips/power

distributors and other electronic devices (such as

halogen transformers) at the back of the appliances.

4.2 Appliance dimensions

Fig. 7 Example illustration

(A)

Appliance height

including feet/

rollers

without handle

[handle depth

= 45 mm (1 6/8 in)]

(B) Appliance width

without handle

[handle depth

= 45 mm (1 6/8in)]

(D) Appliance depth with

open door

A 819mm(32 1/4in)

B 597mm(23 1/2in)

605mm(23 13/16in)

1162mm(45 3/4in)

For appliances with the enclosed wall spacers, the

dimension increases by 35mm(1 3/8in).

4.3 Transporting the appliance

Observe the following when transporting the appli‐

ance:

Transport the appliance upright.

Use two people when transporting the appliance.

During the first use:

Transport the appliance packaged.

During appliance transport or at first use (e.g. when

moving or cleaning):

Empty the appliance.

Secure the door against undesired opening.

4.4 Unpacking the appliance

Check the appliance and the packaging for transport

damage. Contact the supplier immediately if you

suspect any damage. Do not connect the appliance

to the power supply.

Remove all packaging materials from the rear or the

side walls of the fridge that may prevent proper

installation or prevent air flow and ventilation.

Start-up

* Depending on model and options 9
