Fig. 112 Example illustration
(1)
Variable bottle rack
8.7.1 Using the variable bottle rack
Fig.113
u
Lift the glass shelf Fig.113(1) at the front and remove.
u
Store the glass shelf Fig. 113 (1) in a safe place outside
the appliance.
Fig. 114
u
Place bottles in the back row with their bases against the
back wall. (see Fig. 114)
Note
When the bottles protrude over the variable bottle rack at
the front:
u
Set the lower door rack one position higher.
8.7.2 Using the glass shelf
Ensure that the following requirements are met:
q
Bottles have been removed.
q
Variable bottle rack has been cleaned.
(see 9.3 Removing / inserting the variable bottle rack)
(see 9.7.3 Clean the components)
Fig. 115
u
Place the glass shelf Fig. 115 (1) at an angle, sloping it
downwards and backwards.
u
Lower the glass shelf Fig. 115(1) at the front.
8.8 Drawers
You can remove the drawers for cleaning.
The way to remove/insert the drawers varies depending
on the pull-out system. Your appliance can contain various
pull-out systems.
Note
The energy consumption increases and the cooling power
goes down if ventilation is not sufficient.
u
Always leave the fan air vents clear on the back wall!
8.8.1 Drawer on telescopic rails
The drawer runs on extendible rails (telescopic rails). There
are fully extendible telescopic rails and telescopic rails with
partial pull-out. Drawers which are fully extendible can be
pulled out fully from the appliance. Drawers with partial
pull-out cannot be removed fully from the appliance. The
system in your appliance depends on the type of appliance.
Fully extendible*
If you have fully extendible rails, there is a clamp located at
the back on the left and right of the rail.
Removing drawer
Fig. 116
u
Pull out drawer as far as it will go.
u
Lift left clamp and simultaneously pull drawer forwards
on the left. Fig. 116(1)
u
Lift right clamp and simultaneously pull drawer forwards
on the right. Fig. 116(2)
u
Remove drawer to the front. Fig. 116(3)
u
Slide rails in.
Inserting drawer
Fig.117
u
Slide rails in.
u
Place drawer on rails.
Features
26 * Depending on model and options
