Fig. 94
u
Remove the shelf completely: Pull it out to the front.
u
Easier removal: Set the shelf at an angle.
u
Insert the shelf again: Slide it in all the way.
w
The pull-out stoppers point downwards.
w
The pull-out stoppers are behind the front support.
8.4 Dividing shelf
8.4.1 Using the dividing shelf
The shelves are prevented from being pulled out acciden‐
tally by pull out stops.
Fig.95
u
Push the dividing shelf underneath as shown.
Fig.96
Adjusting the height:
u
Pull the glass panels out Fig. 96 (1) from the front, one at
a time.
u
Release the support rails and click in at the height you
want.
u
Slide in the glass panels one at a time.
w
Flat pull-out stoppers at the front, right behind the
support rails.
w
High pull-out stoppers at the back.
Using both shelves:
u
Hold the glass panel with one hand and pull it to the
front.
w
The glass panel Fig.96(1) and trim strip are at the front.
w
The stops Fig.96(3) point down.
Appliances with freezer compartment:*
u
Do not place the support rails and dividing shelf in front
of the fan.*
8.5 VarioSafe *
The VarioSafe offers space in the refrigerator compartment
for small groceries, packages, tubes and jars, for example.
Fig.97
(1)
VarioSafe drawer (3) Recesses on the left and
right side panel
(2) Side panels with ribs
for VarioSafe drawer
8.5.1 Inserting the VarioSafe
Fig.98
u
Insert the VarioSafe into the fridge section at an angle
Fig. 98 (1) until the recesses in the side Fig. 98 (2) of the
VarioSafe are at the level of the support rib in the fridge
section.
Fig.99
u
Set VarioSafe straight. Fig.99(1)
u
Lift VarioSafe at the front. Fig.99(2)
Features
* Depending on model and options 23
